Features:
1) Adopt frequency hopping transmission, strong anti-interference ability. Using 433MHZ, ISM wireless FR transmission technology, transmit power 10DB, receive sensitivity -98DB.
2) With 64 frequency hopping channels, each channel interval 1MHZ.
3) Intelligent wireless technology, automatic frequency hopping, automatic power saving, automatic to learn ID code.
4) Frequency hopping transmission technology, the same room, can support 64 sets of equipment at the same time, do not affect each other.
5) 100PPR manual pulse generator support 10 macro function button.
6) LCD display:Display Y Z A X axis of the mechanical coordinates and workpiece coordinates. Show the spindle speed, the value of the feed rate. Dot matrix LCD with backlight. Axis selection, power band switch control.
7) Axis select band switch to achieve the electronic hand wheel off and the corresponding Y Z A X each axis function of the choice of control. The choice of the step distance value is realized by selecting the switching value band, which is simple and convenient.
8) The series of remote control, providing DLL library files for customers to carry out the 2 development, suitable for the customer's own a variety of numerical control system. The series of remote control, based on the WINDOWS system.
WHB04B Axis:
WHB04B-4: Support 4 axis with X, Y, Z, A
WHB04B-6: Support 6 axis with X, Y, Z, A, B, C
Parameters:
Communication channel: ISM, 433MHZ
Power: two AA alkaline batteries
Wireless transmission distance: 40 meters barrier-free
Encoder: 100PPR
Button: 16 (supports 10 macro code buttons)
Transmitting power: 10DB
Acceptance sensitivity: -98DB
Maximum number of axes: 6 axes
Display: dot matrix LCD backlit display
Material: ABS and PC materials, good resistance to drop and heat resistance, and silicone sleeve protection
