CNC Extension Kit Upgrade Kit 3018 To 3040 Compatible With CNC Engraving Milling Machine
Upgrade your 3018 CNC X-axis with 390mm T8 lead screws and aluminum knobs for even easier handling.
Compatible with most 3018 Pro series CNCs, 3018 Pro, 3018 Pro Max, etc. Note that your 3018 CNC should be equipped with 8mm T8 post screws, 10mm rails, and no holes for the rail end plates.
Upgrade 3018 CNC's great value product and get one size bigger.
Easy to assemble.
/
CNC 3018 PRO Extension Kit for 3018 Pro Series Router Machine / Laser-Machine
This 3018 extension kit can provide your existing 3018 Pro engraving machine with a larger engraving area, easily transforming from 3018 to 3040. This product is easy to install, just install part of the expansion kit.
Note: THIS VERSION IS E480, 300*360 ACTUAL STROKE. THIS KIT ONLY FIT FOR EXTENSION YOUR CNC'S Y-AXIS.
Type:A / B
color:Black + Silver
Material:Aluminum alloy
Package Contents:
1 x Expansion Board
2 x Countertop Connection Plate A
1 x Countertop Connection Plate B
2 x Countertop Connection Plate C
2 x 2040 aluminium profiles (450mm)
1 x 8 mm T8 screw (390mm)
1 x 8 mm T8 screw (470mm)
2 x 10 mm guide rods (450mm)
2 x knobs
2 x Nuts
24 x Slider Nuts
2 x M5X14 screw
8 x M5X16 screw
8 x M5X20 screw
8 x M5X24 screw
/
1 x Expansion Board
2 x Countertop Connection Plate A
1 x Countertop Connection Plate B
2 x Countertop Connection Plate C
1 x 8 mm T8 screw (L:500mm)
2 x 10 mm linear guides (L:480mm)
2 x 2040 aluminum profiles (L:480mm)
1 x Knob
2 x oblong nuts
24 x Slider Nuts
2 x M5X14 screw
8 x M5X16 screw
8 x M5X20 screw
8 x M5X24 screw
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
|
