CNC 1.5kw 220v/110v Square Air Cooling Spindle Kit ER11 1500W Air-cooled Milling Spindle Motor+1.5KW VFD Inverter+13pcs/set ER11
Parameter:
Inverter:
Input Voltage:110V/220V
Output Voltage:110v/220v
Input Frequency:50/60hz
Output Frequency:0.5-400hz
Rated Current"11A
Input Phase:1 phase/3phase
Output Phase:3phase
Suitable for all kinds of machinery, such as winding machines, mixers, extruders, slitting machines, winders, compressors, fans, pumps, grinding machines, conveyors, elevators, centrifuges and other speed control machines.
If you need the manual,please click this link:
https://my.pcloud.com/publink/show?code=XZe2knkZ4tOsWHSArLSwCv61IerS9pJvSklV
Features:1) PID control: advanced calculus PID closed-loop algorithm, fast response and strong adaptability;2) Simple PLC function can realize 16 speed and inverter control function;3) RS485 communication port, using international standard MODBUS main circuit control, strong anti-interference ability;4) Low output torque 0.5HZ-150%, low speed operation capability;5) Carrier adjustable 16KHZ, completely silent working environment;6) Wide voltage working area, 304V-456V normal operation;7) Automatic voltage regulation (AVR) technology to ensure inverter load capacity;8) Synchronous and non-synchronous control techniques,9) Dynamically achieve fast start without changing the brake;10) It has perfect error protection and short-circuit protection protection;11) Dead zone compensation and automatic torque slip compensation function, can achieve 180% high torque output at low frequency 0.25Hz;12) Unique EMC design to minimize the pollution of the inverter to the power supply;13) The overall reinforcement layer adapts to various harsh environments
Spindle:
Power:1500WVoltage:110V220VSpindle: Brushless
Frequency:0-400HzSpeed:0-24000rpmWater Cooling ER11colletRunout off:less than 0.005mmGrease Lubrication
Features:1. Adopting precision steel ball retainer, the rotation precision is higher, which ensures the rotation precision of the electric spindle during high-speed grinding.2. Fan cooling, no water pipe, direct connection, more convenient.3. The spindle is lubricated with 200 degree high temperature grease.4. The body is made of greased stainless steel to keep the body clean and not easy to rust.5. 24,000 ultra-high speed rotation per minute, running smoothly, running sound is only 50-60 decibels, low noise.Package Includes:1pcs1.5kw Spindle Motor1pcs1.5kw Inverter（YL Inverter）13pcs ER11 Collet (1-7mm)
