Water-Cooled Spindle Motor 220V 800W 1.5KW 2.2KW For Engraving Machine With 4 Bearings
Note:
The link is a multi model product. If the details are incomplete or not in conformity with the model you purchased, please use the manual in kind, thank you!
Product parameters
Power: 800W 65x158 ER11
Voltage: 220V (must be approved by the inverter output, can not be directly used ordinary household electric)
Current: 5A Frequency: 400Hz
Diameter: 65mm*158mm Speed :0-24000 rev / min
Clip knife diameter: 7mm, 6.35mm, 6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)
Cooling: water cooling Spindle Weight: 2.5kg
--------------------------------------------------------------------------------------------------
Power: 800W 65x195 ER11
Voltage: 220V (must be approved by the inverter output, can not be directly used ordinary household electric)
Current: 5A Frequency: 400Hz
Torque: 0.61Nm Diameter: 65mm*195mm
Speed :0-24000 rev / min
Clip knife diameter: 7mm, 6.35mm, 6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)
Cooling: water cooling Spindle Weight: 3kg
Bearing: 4pcs
--------------------------------------------------------------------------------------------------
Power: 1.5KW 80x188 ER11
Voltage: 220V (must be approved by the inverter output, can not be directly used ordinary household electric)
Current: 5A Frequency: 400Hz
Diameter: 80mm*188mm Speed :0-24000 rev / min
Nut Model: ER11-A-type Cooling: water cooling
Spindle Weight: 4kg
--------------------------------------------------------------------------------------------------
Power: 1.5KW 80x213 ER16
Voltage: 220V (must be approved by the inverter output, can not be directly used ordinary household electric)
Current: 5A Frequency: 400Hz
Diameter: 80mm*213mm Speed :0-24000 rev / min
Nut Model: ER16-A-type Cooling: water cooling
Spindle Weight: 4.3kg
Product parameters
Power: 2.2KW 80X213MM ER20
Voltage: 220V (must be approved by the inverter output, can not be directly used ordinary household electric)
Current: 8A Frequency: 400Hz
Diameter: 80mm*213mm Speed :0-24000 rev / min
Nut Model: ER20-A-type Cooling: water cooling
Spindle Weight: 6.0kg
