Product features1, tension range is large, using the latest wire jump preventer guards against structure;2, the precision of tension scale corresponding value unification, convenient debugging on multiple machines;3, installation hole diameter of 016 mm, vertical structure, the line in the tension rod swing has big long;4, tension of NS by magnetic field generated, no mechanical friction, tension stable performance is good;5, the main parts: 0 ring, bearing all adopt imported high quality products;The test conditionsLinear velocity of 10 m/s, instant startup, stop line continuously, and stable state of constant velocity winding tension in the go plus or minus 1%Matters needing attention1, read product manual carefully before use;Damping round 2, if stop using for a long time, jitter, before turning to demagnetization process: first, the tension adjustment to the maximum and then immediately counterclockwise clockwise adjust to minimum can complete demagnetization process;3, debugging, to adjust the tension in need to the size of the scale, then adjust the tension knob makes the tension lever between the two red line;4, tension values will not come up:1) the baize pre-tightening force is insufficient, the baize clamping force should be adjusted;2) 0 ring and sheep felt too dirty, clean or replace in time;5, adjusting the tension size or the tension size, should first stop winding machine work;6, the thickness of the wool felt size please refer to our factory to change the specifications, otherwise cause a line is not smooth.
\\\ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \
| \ QH19-MTC | ||
| (gf) | (mm) | |
| QH19-MTCSS | 4-100 | 0.025-0.12 |
| QH19-MTC300S | 14-400 | 0.06-0.30 |
| QH19-MTCS | 50-900 | 0.10-0.50 |
\\
'
