Affordable Wholesale 3000LB 12V Electric Winch With Wireless Remote Trailer 4X4 Truck Boat Atv SUV

SKU: 1005003938649330
Safe Payment Guarantee:

3000LB 12V Electric Winch With Wireless Remote Trailer 4X4 Truck Boat Atv SUV


    • Product Description

      This Electric Winch is a must-have for recovery applications and it's really easy to use. Includes everything you need for setup and operation. Great to be used in ATV.

      Advantages:

      Permanent magnet motor draws less current, ideal for ATV use.
      Differential planetary gear system for fast line speed and sure hold.
      Automatic load-holding brake for maximum safety.
      Cam action clutch for free-spooling (fast line-out without using electric power).
      Longer life and better performance. Fast, powerful and reliable in extreme conditions.

      Notice:

      1. Read the instruction manual carefully before operating! Keep safety consciousness at all times.
      2. Keep hands and body away from fairlead (cable intake slot) when operating.
      3. Do not use winch as a hoist, do not use for transportation of people.
      4. Don't operate and spool under full load over one minute continuously.
      5. Do not exceed winch load weight capacity. While motor is over heating, please stop for a while to cool down.

      This product is guaranteed for 24 months against defective materials and workmanship. The guarantee excludes the wire rope, damage caused by misuse, failure to follow the instructions, or submersion.


            • Feature
                    • Brand new

                    • Electric winch

                    • Fits ATV, UTV

                    • Permanent magnet mator

                    • 2 stage planetary gear train

                    • 4-Way roller fairlead

                    • Wireless Remote Control

                    • Easy to use

                    • Maximum safety

                    • Fast line speed and sure hold

                    • Fast line-out without using electric power

                    • Longer life and better performance

                    • Fast, powerful and reliable

                    • Guaranteed for 24 months


                    • Specifications

        • Product Type: 12V Electric Winch

        • Surface Finish: Black

        • Rated Line Pull: 3000lb (1360kg) Single Line

        • Motor: 3hp 12V, Permanent Magnet Mator

        • Gear Train: 2 Stage Planetary

        • Gear Reduction Ratio: 271:1

        • Clutch: Rotate 90°

        • Cable(Dia x L): 0.19" x 42.65'(4.76mm x 13m)

        • Drum Size(Dia x L): 1.5" x 2.9"(38mm x 74mm)

        • Duty Cycle: Intermittently

        • Fairlead: 4-Way Roller Fairlead

        • Mounting Bolt Pattern: 3.2" x 6.5"(82mm x 165mm)

        • Overall Dimensions(L x W x H): 12.2" x 4.5" x 4.7"(310mm x 115 mm x 120mm)

        • Gross Weight: 26lbs(12kg)

        • Placement on Vehicle: Front, Rear

        • Warranty: 2 Years


      • Package Content

      • 1 x 3000lb Winch

      • 1 x Predrilled Mounting Plate

      • 1 x Clevis Hook

      • 1 x New Style Wireless Remote Control

      • 1 x Sealed Solenoid

      • 1 x 4 Way Fairlead Roller

      • 1 x Bar Mount Rocker in/out Control

      • 1 x Next Generation Control Box

      • 1 x Galvanised Wire Rope

      • 1 x Set of Stainless Steel Fitting Bolts

      • 1 x Instruction Manual
