220V 100W PROXXON Mini Milling Machine MF70 Bench Driller Woodworking Lathe with Optional Dividing Head Chuck Tungsten Steel Cutter Bits Vise
MF70 Lathe
Introduction
Base of grey cast iron. Including both vertical column and compound table of treated, quality aluminium. All axes are play-free and have adjustable gibs. Headstock of die-cast aluminium contains the 24 pole special (balanced) motor is super stable even at high operating speeds. This stability facilitates the use of the finest cutters. The triple slit, hardened steel MICROMOT collets cover 1.0 - 1.5 - 2.0 - 2.35 - 3.0 - 3.2mm. The table is fitted with 3 T-slots of the 12 x 6 x 5mm MICROMOT norm. An adjustable ruler scale eases the positioning of the workpiece. All handwheels are zero adjustable with 1 revolution = 1.0mm, 1 division = 0.05mm.
Technical data
Votage: 220 - 240V,
Power: 100W
Spindle speed: 5,000-20,000rpm.
Footprint size: 130 x 225mm
Table size: 200 * 70 mm
X axis Stroke: 134mm
Y axis stroke: 46mm
Z axis stroke: 80mm
Overall height: 370 mm
Gross Weight: 8.5 kg
The clamping blocks depicted are included too, but not the workpiece!
Tungsten steel milling cutter for micro milling machine MF70 (three-piece set)
The double groove milling cutter is made of strong tungsten steel. The fishtail shape can ensure cutting to the center, and it can also be drilled. Suitable for cast iron, hardened cast iron, steel, cast steel, brass, aluminum, even glass, plastic or carbon fiber.
The tool shank diameters are:
Diameter 1.0 mm
Diameter 2.0 mm
Diameter 3.0 mm
NO24264 dividing head PROXXON mini magic indexing plate for MF70 and KT70.
Indexing head for micro milling machine MF70 and cross table KT 70
Used for drilling eccentric holes and milling eccentric long round holes, rectangular holes, hexagonal holes, etc. The scale on the housing makes it highly accurate.
Chuck with positive and negative clamping: 1.5-32 mm (positive jaw) and 12-65 mm (reverse jaw) can be clamped. When used in a horizontal position, longer workpieces can pass through 11 mm perforations.
NO 24 264
Size: 72*64*38mm
Weight: 900g
PROXXON Mini Vise Jaw for Woodworking Lathe 50*10mm
Die-cast zinc manufactured with three machined sides. The square holes are suitable for MB140/S drill frames and station drill TBM220 adjustable bezels. There are horizontal and vertical V-shaped notches in the jaws. The jaws are 50 mm wide and 10 mm high. The maximum clamping width is 33mm.
