Affordable Wholesale ZBAITU Laser Engraving 81x46cm/80x80cm Diode Wood Router Engraving and Cutting Machine Built-in Air Assist

SKU: 1005004792635893
Safe Payment Guarantee:

M81-C40-5W, M81-C80-10W ,M81-FF80-EAIR-10W ,M81-F20-VF-20W ,M81-F20-PF-20W,All of them are 81x46cm Engraving area

EX-F20-VF-20W, EX-F20-PF-20W,The Engraving area of these two models are 80x80cm

ZBAITU is a professional manufacturer that is concerned with the design, development and production of DIY Laser Engraver Printer. All of our products comply with international quality standards and are greatly appreciated by customers all over the world.

We would like to provide the best Laser Engraver Equipment and Service for you.

About The Air Pump and Rotary Roller

1. Our machine accessories are complete and can be used directly after receiving the package. If you have more budget, you can buy an air pump, and the laser head with air assist function can be connected to the air pump. The air pump will exhaust the smoke produced by the cutting

2. The rotary roller can be used to carve cylindrical objects

Welcome to share your any ideas with us!!

We specially upgraded the working area of M81 at the request of customers. Now the engraving area can reach 80x80CM.  That is almost the largest engraving size in the market for such laser machine.

The upgraded machine only needs to replace the two shorter steels with 958 cm, and other installation steps are the same as the original M81 installation.

This large area engraver came with the most popular high power modules with air assist systems: the FF80-EAIR and FF100

FF80-EAIR has 10W laser out,  FF100 is 15W laser out.

If you have our M81 laser machine, just need to extend the working size, then you just need choose the kits.

ZBAITU Laser Engraving 81x46cm/80x80cm Diode Wood Router Engraving and Cutting Machine Built-in Air Assist

Strongest Laser Power 20W;  Smaller Size 8*8*7CM; High Airflow; Thicker Cutting Capacity; Faster Cutting Speed

▶ Strong Compatibility: The F20-VF laser module can be installed on any engraving machine model of ZBAITU laser engraver M37, M81 FF80, A40, M81 FF80 EAIR and it can be used without any additional settings. .

▶ Two Fans: The double-sided fan can effectively reduce the temperature when the laser is working, protect the driver of the laser, prolong the service life of the laser.

▶ Updated Air Assist : In order to make the air intake meet the needs of cutting and engraving, we increased the air intake from the original 3.5MM to 7MM. Now the cutting lines are thinner and the cutting speed is faster.

▶4 IN 1 Diode High Energy and Faster Speed: 20W laser power engraver. The laser output power soars up with the latest generation of four 5W laser coupling technology, which is able to cut off 12-15mm thick plywood, the 8mm thick black acrylic board with only one pass, and even cut the 0.05mm thick stainless steel sheet.

▶ Upgraded Laser: No need to adjust the focus before engraving. The focusing spot area is only 1/3 of other ordinary lasers. Combine precision engraving and high energy cutting at the same time. The laser power of the fixed-focus laser is more stable than the zoom laser.

▶ Various Material to Cut and Engrave: Engraving materials are including wood, bamboo, cardboard, plastic, leather, PCB board, aluminum oxide, non-reflective electroplating layer and lacquered metal, after blackening Utility knife. Cutting materials are including cardboard, non-woven fabric, veneer, acrylic, some thin plastic board

Module Model: F20-VF

Laser type: Diode

Diode No.: 4

Optical Output Power: 20W

Product Material: Aluminum 6061 Anode

Housing Size: 15*16*6CM

Circuit Board Size: 44*52mm

Circuit Board: V/PWM Modulation Board

Wire Rod: 22# 2P2.54 Terminal Reverse Wire 80mm

Optical Lens: φ6/glass

Laser Beam Mode: Spot

Working Mode: Pulse Work

Light Spot Size: 0.08*0.1mm

Wavelength: 445±5nm
