Feature
Adopt Sony new generation high dynamic range CMOS image sensor;
Adopt 1/2-inch image sensor;
HDMI 1080P 60 frame image output;
Support photo, JPG format and Video Storage;
Support manual one-key exposure
Support manual one-key white balance, red, green and blue adjustable;
Provide 8 line drawing functions, the line color, thickness, and position are adjustable;
Support U disk storage;
Picture is clearer without shaking;
Support English Chinese French German Italian Spanish Russian Portugu Korean menu languages (default English);
Support shutdown setting parameter saving;
se CNC precision milling technology to process aluminum alloy shell;
Specifications
Sensor: 1/2 inch Sony CMOS sensor
Pixel size: 3.75µm ×3.75µm
USB interface: USB2.0 (plug in U disk )
HDMI output: 1920*1080 60 frames
Lens interface: C interface
Exposure: One-click exposure
White balance: one-key white balance
Storage: Support U disk storage
Input voltage: DC 5V-12V
Scribe: support 8 straight lines, color, thickness and position are adjustable
Mirror: support horizontal/up and down roll
Menu language: English Chinese French German Italian Spanish Russian Portugu Korean
Preparation for use:
1. Unscrew the lens cap and install the lens;
2. Plug in the HDMI cable and DC power supply, and the LED light is on at this time, indicating that the camera has been turned on;
3. After inserting the mouse into the USB interface, use the mouse for setting operations. Right-click on any blank place to display the main menu, click again to hide the menu, and the menu will be automatically hidden after 30 seconds without any operation.
8X-100X Zoom C-mount Lens:
Work distance: 40mm-400mm
Zoom ratios: 1:17
Magnification Power by 0.12 - 2X (about 8X - 100X on the Monitor)
view field of Max multiple : 5.4mm*3mm
view field of Min multiple : 54mm*30mm
Size: 115mm(L) * 40mm(DIA)
Weight: 210g
10X-130X C-MOUNT Lens:
Working distance: 60mm-300mm
zoom ratios: 1 : 11
Magnification Power by 0.1 - 1.3X (about 10 - 130X on the display)
view field of Max multiple : 8mm*4.5mm
view field of Min multiple : 40mm*33mm
Size: 30mm(diameter) * 84mm(length)
Weight: 180g
10X-180X C-MOUNT Lens:
Working distance: 100-150mm
Zoom ratios: 1:6.5
Magnification Power by 0.7 - 4.5X(about 15 - 180X on the display)
view field of Max multiple : 2.8mm*1.5mm
view field of Min multiple : 25mm*14mm
Eyepiece lense : 0.5X
Size: 168mm(L) * 50mm(DIA)
Weight: 600g
20X-300X C-MOUNT Lens:
Working distance: 90-100mm
Zoom ratios: 1:6.5
Magnification Power by 0.7 - 4.5X(about 20 - 300X on the display)
view field of Max multiple : 1.4mm*0.8mm
view field of Min multiple : 10mm*5mm
Eyepiece lense : 1X
Size: 245mm(L) * 50mm(DIA)
Weight: 630g
10X-200X C-mount Lens:
Working distance: 90MM-100MM
zoom ratios: 1 : 7.2
Magnification Power by 0.7- 5X (about 10 - 200X on the display)
view field of Max multiple : 3.2mm*1.8mm
view field of Min multiple : 37mm*21mm
Eyepiece lense : 0.4X
Size: 55mm(diameter) * 132mm(length)
Weight: 455g
25X-500X C-mount Lens:
Working distance: 90MM-100MM
zoom ratios: 1 : 7.2
Magnification Power by 0.7- 5X (about 25 - 500X on the display)
view field of Max multiple : 1.3mm*0.7mm
view field of Min multiple : 9mm*5mm
Eyepiece lense : 1X
Size: 55mm(diameter) * 175mm(length)
Weight: 510g
56 LED Adjustable Compact Microscope Ring Light
Provides intense and focused shadow-free illumination
56 bright white LED bulbs
Lighting direction changeable
Variable intensity control
Intense and focused shadow-free illumination
100,000 hours of life
Power input: 100-240V, 50-60HZ, auto switching
Inside diameter of the ring light: 1.0" (27mm)
Overall outside diameter: 1.77" (45mm)
Working Distance: 27mm-120mm
Package incluede:
1 x Video Microscope Camera
1 x Power supply
1 x HDMI line
1 x Remote Control
Optional Accessories Incluede:
1 x C-MOUNT Lens
1 x 56 LED Adjustable Microscope Ring Light
