Automatic Solder Paste Mixer 500g-1000g ZB500S for Repairing PCB
Technical parameters:
Type |
ZB500S |
Operating speed |
Motor speed: 1350RPM |
One revolution: 400RPM; Two rotations: 300RPM |
|
Operational capability |
0-1000 g * 2 tanks |
Acceptance of solder cream pot |
Tank diameter Φ60-Φ67 standard configuration (suitable for general 500 g solder cream bottle) Other specifications, please contact us for customization. |
Time setting |
0.01s～99H99s, minute and second set |
Display mode |
LED digital display |
Rated power |
Constant speed 60W |
Working power supply |
AC 220V±10％ 50Hz |
Boundary dimension |
400×400×500mm |
Machine weight |
50kg |
Attachment list:
1. Adjustment belt 2 PCS
2. Rotation belt 2PCS
3. Balance weights 500g 1PCS
4. Instruction book 1PCS
5. Certificate of quality 1PCS
6. Lining 2PCS
