800W DC spindle Motor 0.8KW DC 0-110 CNC Carving Milling Air cold Spindle Motor For Engraving
Spindle Motor Parameter:
Work voltage: 110VDC
Rotation speed: 20000r/min
Power: 800W
Torque:0.79NM
Insulation resistance:>2Megohm
Dielectric strength:400V
Total length: 203.5mm
Diameter:52mm
Axis collet Length: 45mm
Chuck part size: 35mm shank part (total length 43mm including nut and sandwich)
This product is equipped with ER11-3.175MM collet and ER16-8MM collet by default,
This product is equipped with ER11-3.175MM collet and ER16-8MM collet by default,
Precautions
Spindle Arbor ER11 Arbor Clamp (1mm-7mm) Default Hair 3.175MM Chuck
Spindle Arbor ER16 Arbor Clip (1mm-10mm) Default Hair 8 MM Chuck Drill chuck
Spindle Arbor (Drill chuck Clamping range：1.5-10mm)
Need other chucks to leave a message
For other sizes, please contact customer service.
Total motor length: 203.5mm (including clamping part and motor)
Net weight of spindle: 990g
Spindle radial runout is about 0.01-0.03.
Can be used for engraving materials such as metal or non-metal.
The spindle comes with forced air cooling, and the external carbon brush can work for a long time.
