3018 Pro Y-Axis Extension Kit Upgrade 3018 To 3040 Laser Machine Compatible with 3018 Pro CNC Engraving Milling Machine
Package Includes:
2 x 45cm Y-axis aluminum profile
2 x 45cm Y-axis optical axis
1 x 47cm Y-axis screw
1 x handwheel
2 x limit switch
Features:
【3018Pro Y-Axis Extension Kit】Do you want to get a LARGER engraving area for your existing 3018Pro CNC? 🧐 Try this kit to extend the total length of the Y-axis of 3018pro from 290mm to 445mm!
【Upgraded Engraving Area】This kit can extend the Y-axis of 3018Pro CNC to 370mm (14.6") movement, 320mm (12.6") travel, easily convert 3018 to 3040.
【Simple Assembly】Just disassemble the original Y-axis part and install the extension kit.
【Cost Effective】You can experience a bigger CNC for less money.
Notice:
The limit switch is installed on the engraving machine, the software needs to set the following parameters
① If installed to a three-axis engraving machine
Setting parameters:
$21=1 $22=1 $23=3
② If installed to a two-axis laser engraving machine
Setting parameters:
$21=1 $22=1
How to install ?
