Specifications:
Jaws material: Hardened Steel
Model: K13-160
Max RPM: 2500 r/min
Jaw: 6 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting .
2. K13 chcuks are matched with stepped jaws.
3. Suitable for clampong and machining the thin-inwalled somponents.
4.Especially suitable for matchining all kinds of cutting tools with handles.
Internal Jaw:
Clamping Range A-A1: 3- 55mm
Jamming Range B-B1: 50- 160mm
External Jaw
Clamping Range C-C1: 55- 145mm
Packaged included :
Self-Centering chuck body x1
A set jaw x6 (Already install on chuck body)
Safety chuck key x 1
Mount screw x 3
