Specifications:
Name: Hydraulic Manual Control Valve
Model: ZSL-118
Diameter: 10mm
Connection method: threaded connection
Control method: manual control
Flow: 40L/min
Nominal pressure: Rated 16 MPa, Max. 20 MPA
Application: Large tractor, etc.
ZS-L118 series multi-way reversing valve is a set of oil inlet, oil return and reversing
valve casting. It has the characteristics of compact structure, high working pressure and
reliable performance. The biggest feature of this valve is that it uses a direct-acting safety
valve, which solves the shortcoming that the previous pilot-operated safety valve is easy
to die, and greatly improves the anti-fouling performance of the multi-way valve. Widely
used in forklifts, loaders, excavators, cranes, road rollers and other construction machinery
and mining, light industry, sanitation, agricultural machinery and other industries. It is used
to change the direction of liquid flow and realize the centralized control of multiple actuators.
