1X 7'' HMI+PLC All-in-one Controller
1X PLC Programming Cable
1X Type-C HMI Download Cable
4X Mounting screws
0-10V 6AI 2AO: 6PCS 0-10V Analog Input, 2PCS 0-10V Analog output
0-20mA 6AI 2AO: 6PCS 0-20mA Analog Input, 2PCS 0-10V Analog output
☑ Note:
1. We can customize Max 3PCS NTC Thermistor, 3PCS E/K/J thermocouple, 1PC Load Cell Analog Input,
Can Port Modbus, RS485, please contact us if you need it.
2. The high-speed pulse of this controller is only 10KHz, if you need to control step/servo motors, please contact us.
3. After purchase, we will provide manuals and free softwares.
4. If you encounter any questions, please contact us directly.
☑ Electric Parameters:
Input voltage: DC 24V
☑ Parameters of HMI Part:
Dimension: 210*146*36mm
Display size: 7 Inches TFT (154*87mm)
Cutout size: 192*138mm
Resolution: 800*480 pixels
RAM: NOR Flash 16MB
ROM: 64MB
CPU: 32bit CPU 408MHz
Download Port : Type-C
Features: 60K colors resistive panel, can be displayed in portrait
Display Language: Chinese and English
☑ Parameters of PLC Part:
Analog Input: 6 0-10V/0-20mA (Max 6AI)
Analog Output: 2 0-10V/0-20mA (Max 2AO)
Accuracy: 12 bits
Digital outputs (DO) type: Transistor Output
Digital I/O: 24DI/20DO
Input I/O level: Passive NPN, public terminal isolated
Transistor output I/O level: NPN
Allowed max current: MOS: 2A/ Transistor: 500mA
Loom voltage: DC12V~48V
Circuit insulation: Optocoupler insulation
Isolation voltage (power supply - external terminal):1500V AC
On response time: High speed output 10μs, others 0.5ms
High speed pulse: 4 Channles 10KHz
High speed output frequency: Y3-Y0 is 10KHz
PLC switch: Move the DIP switch on the back of the panel to "R" (Run)
PLC communication port: 1 RS232 programming port
Output level: Normally open dry contact output, COM port can be connected to positive or negative
Isolation method: Photoelectric coupling
Input resistance: High speed input terminal 3.3KΩ/Ordinary input terminal 4.3ΚΩ
Input is ON: High speed input > 4.5mA/Ordinary input > 3.5mA
Input is OFF: Input < 1.5mA
Filter function: Filter can set from 0-100ms, default as 10ms
High speed counting: 6 single-phase (X0-X5)10KHZ
Input level: COM port connects negative terminal
Working temperature: 0°C~50°C
Relative humidity: 5%~95%RH
