Description:

*1. PCB: 54mm x 85.5mm x 11mm (without the size of connectors, switches)

*2. Measurement Frequency: 50KHz -1.5GHz

*3. RF Output: -13dbm (maximum -9dbm)

*4. Frequency Accuracy: ＜2ppm

*5. Frequency Stability: < 0.5ppm

*6. Measurement Range: 70dB (50kHz-300MHz), 50dB (300M-900MHz), 40dB (900M-1500MHz)

*7. Port SWR: < 1.1

*8. Display: 2.8 inch TFT (320 x240)

*9. USB Interface: USB Type-C; Communications Mode: CDC (Serial)

*10. Power Supply: USB 5V 120mA, built-in 400mAh electricity, maximum charging current 1A

*11. Number of Calibration Points: 101 (Fixed)

*12. Number of Scanning Points: 101 (Fixed)

*13. Display Tracking: 4, Marking: 4, Save Setting: 5

*14. Measuring S parameters, voltage standing wave ratio, phase, delay, Smith chart, etc.

Features:

*1. Lower power supply noise, less noise when using harmonics.

*2. Built-in 400mAh battery, with 2.8" touch screen.

*3. Add a MicroSD card to save the test data easily.

*4. Add RTC support.

*5. Modify the port names to Port1 and Port2.

*6. MicroSD supports up to 32GB, and only supports SPI mode.

*7. Can measure complete S11 and S21 parameters.

*8. If you need to obtain S12 and S22, you need to manually replace the transceiver port wiring.

Package Includes:

1X NanoVNA Host (2.8-inch touch screen and 400mAh battery is included)

2X 20cm SMA Male to Male RG174 RF Cable

1X SMA Female to Female Connector

1X SMA Simple Calibration Kit SHORT

1X SMA Simple Calibration kit OPEN

1X SMA Simple Calibration kit LOAD

1X USB Type-C Data Cable

1X Type-c Line

1X Touch Pen

1X Paddle
