Tips :This PLC is RS232 communication by default,if you need RS485 communication,please choose the right option.RTC means real time clock.RTU meansRemoteTerminal Unit.Features:1. Support human-machine interface link, the application is exactly the same as FX3U2. This PLC adopts industrial-grade 32-bit MCU with strong anti-interference, and its running speed far exceeds the original FX3U.3. Support ladder programming, download and monitoring.4. The programming port is the port for program download and communication with the display unit.5. Write application in ladder language, fit for Mitsubishi GX-Develoer/GX-WORK2Specification:PLC Transmission Baud Rate: 38400Input: 32 PointOutput: 24 RelaysX0-X5 is a high-speed input. It can connect 3 AB encoders. The default is 12K, 100K is optional.6 analog inputs (default 3 channels 0-10V. 3 channels 0-20MA). 2 channels 0-10V analog outputPower-down hold, freely settable, optional CAN communication extensionThe industrial control board is powered by DC 24V. Do not input AC or 220V voltage
