CNC 3040 Aluminum Frame Kit 300*400*120mm Stroke CNC 3018 Plus Nema23 57mm Stepper Motor Spindle Holder Diameter 52mm
Tips:
The machine is all accessories, you need to assemble it by yourself after you receive it.
Feature
Longer 120mm stoke for Zaxis module, XYZ three-axis actual stroke 300*400*120mm, Aluminum Table Size 300*400mm
Z-axis adopts customized holes, no screws are required for installation
12mm optical axis, stable and durable
Ball screw 1204, more precise, higher work efficiency, lead 8MM, POM anti-backlash nut
Screws are equipped with gaskets to protect the machine more,Both screws are equipped with knobs, size 8mm
Spindle hole diameter: 52mm, Laser and spindle switch freely, installation is simple and convenient
Specification
Working area: 300*400mm
Z axis stoke: 120mm ;after install limit switch is 100mm
Screw : ball-screw 1204
Optical axis:Diameter 16mm
Aluminum profile: 2060
Material: Aluminium, Full metal oxidation sandblasting
Stepper motor: Support Nema23 57mm
Horizontal screw seat, inner diameter 8
PS: Equipped with baffle and emergency stop switch hole
