Affordable Wholesale Nanovna-F V2 3Ghz Vector Network Analyzer 4.3 Inch Touch Screen Nanovna Antenna Analyzer With RF Demo Kit

SKU: 1005004254534598
Safe Payment Guarantee:

Nanovna-F V2 3Ghz Vector Network Analyzer 4.3 Inch Touch Screen Nanovna Antenna Analyzer With RF Demo Kit 1. It can measure S parameters, voltage standing wave ratio SWR Smith chart, phase diagram, group delay,etc. 4.3 inch IPS LCD screen, IPS TFT (800x480) viewing angle is close to 180degree, long-term use will not hurt your eyes. The high quality case is used to effectively shield electromagnetic interference, making S21 a dynamic range better than 80dB within 1GHz
2. Compact design, body size 125mm x 75mm x 20mm, compact and portable. The radio frequency interface is SMA, which is convenient for connecting all kinds of DUTs. Using 5000mAh super-capacity lithium battery, the battery life can reach 7 hours
3. Full touch screen design, support 3 side buttons at the same time, flexible and convenient operation. Support Chinese and English menu switching. Support screen brightness adjustment
4. Upgrade firmware through virtual U disk, no programmer is needed, only one USB cable is needed to upgrade firmware. Expand a USB power output interface, 5V/1A output (can be used as a power bank)
5. Using high current 2A charging IC, the charging time is shorter. Support the host computer, you can use the computer as the display operation interface

1. Measuring frequency range: 50KHz-3000MHz
2. RF output power: -9dbm (error within 1GHz: plus or minus 1db)
3. Frequency accuracy: Less than 0.5ppm
4. S21 dynamic range: 70dB (1.5GHz), 60dB (3GHz)
5. S11 dynamic range: 50dB (1.5GHz), 40dB (3GHz)
6.2 Port return loss: 20dB typ (1.5GHz), 13dB min (3GHz)
7. USB interface: USB Type-C communication mode: CDC (serial)
8. Number of calibration points: 101 points
9. Number of scanning points: 101 points
10. Display tracking: 4 tracks
11. Mark: 4 mark points (mark mark bar can be moved up and down on the screen)
12. Setting save: 5 (after saving, it can be directly recalled when it is used next time it is turnedon, no need to recalibrate, the next time it is turned on, the saved parameters before the last shutdown are automatically recalled)
13. Scan time: about 1.9s/1 time (50kHz - 3000MHz full frequency band)
color:Photo color
Material:Aluminum alloy

Package Contents:
1 x Host
1 x SMA open calibration kit
1 x SMA short-circuit calibration kit
1 x SMA 50ohm load calibration kit
1 x SMA-KK double head female hole adapter
1 x SMA-JJ double-head male pin adapter
1 x SMA-JKW elbow outer screw inner hole to inner screw inner needle adapter
2 x 20cm SMA-JJ RG405 RF cable
1 x USB type-C data cable

Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
