Other types of PLC boards need to be configured, please contact the seller!!!
If you need download cable and your computer no 9pin port,please click here : USB TO RS232 cable
If you need macthing switching power supply, please click here : 24V 2A power supply Specification
FX3U series PLC Specification :
Specification of FX3U series PLC:
To buy FX3U PLC only click:
FX3U 14MT/MR
FX3U 24MT/MR
FX3U 30MR/32MT
FX3U 48MT/MR
FX3U 56MR
Features of FX3U-56MR:
1. Support human-machine interface link, the application is exactly the same as FX3U
2. This PLC adopts industrial-grade 32-bit MCU with strong anti-interference, and its running speed far exceeds the original FX3U.
3. Support ladder programming, download, and monitoring.
4. The programming port is the port for program download and communication with the display unit.
5. Write an application in ladder language, fit for Mitsubishi GX-Developer/GX-WORK2
Specification of FX3U-56MR:
conditioning: 100% brand new
PLC Transmission Baud Rate: 38400
Input: 32 Point
Output: 24 Relays
X0-X5 is a high-speed input. It can connect 3 AB encoders. The default is 12K, 100K is optional.
6 analog inputs (default 3 channels 0-10V. 3 channels 0-20MA). 2 channels 0-10V analog output
Power-down hold, freely settable, optional CAN communication extension
The industrial control board is powered by DC 24V. Do not input AC or 220V voltage
