 Software download address:https://share.weiyun.com/5cl0kWUHigh Quality, High Resolution, Clear Images37.0MP 1/2.3 Inch big size Panasonic CMOS Image SensorTF Card Video RecorderPhoto Model / Video ModelIndustry CMOS Camera. It can Show the live image directly on any HDMI monitor , Projector or TV.It builds in digital crosshairs and color control, add line in the pictures, freeze ,Mirror, Rotate, NegativeSupply USB2.0,HDMI HD video,Two outputSpecification:Image sensor: Panasonic sensorFrame rate: 1920*1080@60FPSHousing: Aluminium alloyPixel size:1.43μm × 1.43μmOutput:USB, HDMI, TF card, infrared remote controlSensor size:1/2.3"Power:DC-12V/1AFeaturesBasic function:Brightness, contrast, saturation, white balance,black and white switching, date adjustmentImage adjustment:Exposure, Flicker restrain, Acutance,Gamma, Cb/ Crgain adjustmentCamera function:Digital zoom, Horizontal/vertical mirror, image freezeStorage:Image capture,video, image preview, TF card formattingReticle:4 sets of reticle, can define thecolor, line, displacement, and hiddenCrosshair:Can adjust color, line size, hide or displayWhite balance: Auto/manualTF card interface: Max 64GHDMI interface: Standard HDMI outputHDMI Image resolution:  8168*6128 4:3(50MP) 8168*4592 16:9(37MP) (for TF Card),USB Image resolution: 1920 *1080 (for PC USB)Video resolution: 1920 *1080 @ 60FPS for HDMI, 1920 *1080 @ 30FPS 1280*720@ 30FPS 640*480 @ 30FPS 320*240 @ 30FPS  for USBVideo format: MP4Image format:JPGColor: Color/black and whiteFreeze: SupportExposure:Auto/manualCamera Interface:C CS MountEV:+/-Remote operation:YesLanguage Support :Chinese English French  Spanish  Portuguese  German Italian Simplified Chinese Traditional Chinese Russian Japanese

120x Feature:
Working distance: 90mm-180mm
Zoom C-mount Lens
0.35X C-mount adapter
zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 120X 180X or 300X on the display)
Size: 142mm(L) * 50mm(DIA)


180x Fature:
Working distance: 90mm-150mm
Zoom c-mount Lens
0.5X C-mount adapter
zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 120X 180X or 300X on the display)
Size: 168mm(L) * 50mm(DIA)

300x Feature:
Working distance: 90mm-100mm
Zoom c-mount Lens
1X C-mount adapter
zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 120X 180X or 300X on the display)
Size: 245mm(L) * 50mm(DIA)
New 130x Feature:
Zoom c-mount Lens
Working distance: 70mm-380mm
Field of view: 7mm-43mm
Focal length: 50
Interface: C CS mount
Install diameter：40mm or 50mm
Magnification Power by 0.12 - 2.5X (about 12 - 130X on the display)
Size: 30mm(L) * 84mm(DIA)  Old 130x Feature:
Zoom c-mount Lens
Working distance: 40mm-200mm
Visual field :2.4mm-32mm
Focal length: 40
Interface: C CS mount
Install diameter：40mm or 50mm
Magnification Power by 0.12 - 2.2X (about 8X - 130X on the display)
Size: 115mm(L) * 40mm(DIA)
Long focal 130x Feature:
Material: Metal and Glass
Optical Power:0.1X-2.0X
Electronic Magnification :130X
Installation:C/CS
Image format:2/3
Aperture(D/f): F3.5
Object distance:1.8mm-Infinity
Working distance:50mm-Infinity
Distor tion:0
Resolving Power:1000W
IR CUT FilteR:400-700
Dimensi ons:28X99mm
Zoom ratio:15:1
Working diameter:50mm
Working distance 50mm,1/3sensor:2.4*1.8mm
Working distance 50mm,1/2sensor:3.2*2.4mm
Working distance 50mm,3/2sensor:4.4*3.3mm
Working distance 100mm,1/3sensor:8.7*6.5mm
Working distance 100mm,1/2sensor:12*8.7mm
Working distance100mm,3/2sensor:8.7*6.5mm
Working distance200mm,1/3sensor:21*15mm
Working distance200mm,1/2sensor:28*21mm
Working distance200mm,3/2sensor:38*28mm
Working distance290mm,1/3sensor:31*23mm
Working distance290mm,1/2sensor:41*31mm
Working distance290mm,3/2sensor:57.7*43mm





56 LED Adjustable Compact Microscope Ring Light
Provides intense and focused shadow-free illumination
56 bright white LED bulbs
Lighting direction changeable
Variable intensity control
Intense and focused shadow-free illumination
100,000 hours of life
Power input: 100-240V, 50-60HZ, auto switching
Inside diameter of the ring light: 1.0" (27mm)
Overall outside diameter: 1.77" (45mm)
Working Distance: 27mm-160mm Package incluede:1 x Microscope Camera1 x Power Adapter (AU/EU)1 x IR remoter1 x Usb Lines1 x HDMI Lines1 x Paper Manual1 x 16G TF CardOptional accessories incluede:1 x C-MOUNT Lens(100X or 180X or 300X  or 130x)1 x 56 LED Adjustable Microscope Ring Light
