Model

I/O port

Software

Dimensions
(WxHxD)mm

Panel Cutout
(mm)

MT8071iE

USB2.0/Ethernet

EBpro multiple languages

200.3x146.3x34

192x138

MT8071iP

MT6071iE

USB2.0 Mini USB

MT6071iP

USB2.0 MicroUSB

TK8071iP

Ethernet

TK6071iP

MicroUSB

EBpro Chinese

TK6071iQ

USB2.0

Model

MT8071iE

MT8071iP

MT6071iE

MT6071iP

Display

Display

7" TFT

Resolution

800 x 480

Brightness (cd/ ㎡ )

400

300

300

300

Contrast Ratio

800:1

500:1

500:1

500:1

Backlight Type

LED

Backlight Life Time

>30,000 hrs.

Colors

16.7M

LCD Viewing Angle
(T/B/L/R)

80/60/80/80

70/50/70/70

70/50/70/70

70/50/70/70

Touch Panel

Type

4-wire Resistive Type

Accuracy

Active Area Length(X)±2%,
Width(Y)±2%

Memory

Flash

128 MB

RAM

128 MB

Processor

32-bit RISC 600MHz

I/O Port

USB Host

USB 2.0 x 1

USB 2.0 x 1

USB 2.0 x 1

USB 2.0 x 1

USB Client

N/A

N/A

USB 2.0 x 1

USB 2.0 x 1 (Micro USB)

Ethernet

10/100 Base-T x 1

10/100 Base-T x 1

N/A

N/A

COM Port

COM1: RS-232
COM2: RS-485 2W/4W
COM3: RS-485 2W

COM1: RS-232 4W
COM2: RS-485 2W/4W

COM1: RS-232
COM2: RS-485 2W/4W
COM3: RS-485 2W

COM1: RS-232
COM2: RS-485 2W/4W

RTC

Built-in

Power

Input Power

24±20%VDC

10.5~28VDC

24±20%VDC

10.5~28VDC

Power Isolation

Built-in

Power Consumption

450mA@24VDC

1A@12VDC ; 500mA@24VDC

350mA@24VDC

1A@12VDC ; 500mA@24VDC

Voltage Resistance

500VAC (1 min.)

Isolation Resistance

Exceed 50MΩ @ 500VDC

Vibration Endurance

10 to 25Hz
(X, Y, Z direction 2G 30 minutes)

Specification

PCB Coating

Yes

Enclosure

Plastic

Dimensions WxHxD

200.3 x 146.3 x 34 mm

Panel Cutout

192 x 138 mm

Weight

Approx. 0.6 kg

Mount

Panel mount

Environment

Protection Structure

NEMA4 / IP65 Compliant Front Panel

Storage Temperature

-20° ~ 60° C (-4° ~ 140° F)

Operating
Temperature

0° ~ 50° C (32° ~ 122° F)

Relative Humidity

10% ~ 90% (non-condensing)

Certificate

CE

CE marked

ATEX

ATEX Zone 2/22
Category 3 G/D

N/A

N/A

N/A

Software

EasyBuilder Pro
EasyAccess 2.0 (Optional)

EasyBuilder Pro
EasyAccess 2.0 (Optional)

EasyBuilder Pro

EasyBuilder Pro
EasyAccess 2.0 (Optional)

Model

TK8071iP

TK6071iP

TK6071iQ

Display

Display

7" TFT

Resolution

800 x 480

Brightness (cd/ ㎡ )

300

Contrast Ratio

500:1

Backlight Type

LED

Backlight Life Time

>30,000 hrs.

Colors

16.7M

LCD Viewing Angle
(T/B/L/R)

70/50/70/70

Pixel Pitch (mm)

0.1926(H) x 0.179(V)

Touch Panel

Type

4-wire Resistive Type

Accuracy

Active Area Length(X)±2%,
Width(Y)±2%

Memory

Flash

128 MB

RAM

128 MB

Processor

32-bit RISC 528MHz

I/O Port

USB Host

USB 2.0 x 1

N/A

USB 2.0 x 1

USB Client

N/A

USB 2.0 x 1 (Micro USB)

N/A

Ethernet

10/100 Base-T x 1

N/A

N/A

COM Port

COM1: RS-232 4W
COM2: RS-485 2W/4W

RTC

Built-in

Power

Input Power

10.5~28VDC

Power Isolation

Built-in

Power Consumption

1A@12VDC ; 450mA@24VDC

550mA@12VDC ; 300mA@24VDC

1A@12VDC ; 450mA@24VDC

Voltage Resistance

500VAC (1 min.)

Isolation Resistance

Exceed 50MΩ @ 500VDC

Vibration Endurance

10 to 25Hz
(X, Y, Z direction 2G 30 minutes)

Specification

PCB Coating

Yes

Enclosure

Plastic

Dimensions WxHxD

200.4 x 146.5 x 34 mm

Panel Cutout

192 x 138 mm

Weight

Approx. 0.52 kg

Mount

Panel mount

Environment

Protection Structure

NEMA4 / IP65 Compliant Front Panel

Storage Temperature

-20° ~ 60° C (-4° ~ 140° F)

Operating
Temperature

0° ~ 50° C (32° ~ 122° F)

Relative Humidity

10% ~ 90% (non-condensing)

Certificate

CE

CE marked

ATEX

N/A

Software

EasyBuilder Pro
EasyAccess 2.0 (Optional)

EasyBuilder Pro

EasyBuilder Pro
EasyAccess 2.0 (Optional)
