Seller recommendation:

• 0.5W/2.5W/5.5W is a focus-adjustable laser with low laser power. It is recommended to engrave pictures and can only cut thin cardboard.

• 15W/30W/40W lasers are all fixed-focus lasers, focus cannot be adjusted, and the power of the laser can be controlled by software；

• 15W/40W laser, both can engrave on stainless steel and coated metal, and can engrave frosted stone；

• 15W/40W/80W laser, the greater the power, the faster the engraving speed, the thicker the cutting thickness, and the fewer times of cutting;

• 15W laser is recommended for cutting 1-3mm cork board 40W/80W laser is recommended for cutting 3-5mm cork board

Specification:

• Input voltage：AC 100V-240V，50 / 60Hz

• Output：DC 12V 5A

• Engraving area：395*285mm

• Support software include: weidiao master, GRBL. etc.

• Support PWM TTL modulate laser power

• Support gray engraving, sketch route cutting, line scanning engraving, spot engraving.etc.


Tips:Please contact us for SOFTWARE AND INSTRUCTION MANUAL download link!

  0.5W-15W Laser Module Parameter:

• Engraving distance:less than 3cm

• Laser wavelength: 445nm-450nm blue laser

• Spot type: dotted (adjustable)

• Output power: 2.5W, 3.5W, 5.5W

• Size: 33*70mm

• Drive mode: external ACC constant current drive

• Cooling method: forced air cooling

• Operating voltage: 12V  DC

• Control interface: 2 * 2.54 (TTL control switch, PWM control power)

• Shell material: aluminum, surface anodized

• Collimator lens: optical glass coating

  40W Laser Module Parameter:

• Module Input：40W

• Optical power output：5.5W

• Wavelength：450nm

• Beam Shape：Dot(fixed focues)

• Working Voltage：DC 12V

• TTL&PWM Modulation：YES,

• Compatible with Both TTL & PWM

• ModulationInput Voltage：DC12V 3-4APWM/TTL

• Input：DC 5V

• Input Interface：3Pin (+,-, PWM/TTL) , 2Pin+2Pin (+,-) + (PWM/TTL,-)

• Safe temperature range：<60 ℃

• Module weight：202g ( The lighter the weight, the smaller the move inertia, the better the performance

• Life Time：10000-20,000 hours


   80W Laser Module Parameter:

• Effect output power: 80W

• Material: aluminum alloy + plastic

• Light color: blue

• Wavelength: 450nm

• Spot form: Punctiform, fixed focus

• Input voltage: 12V 3.2A / 24V 1.7A

• Input port: XH2.54-3P socket

• Interface parameters: support TTL signal control power

• Laser module net weight: 300g


Machine Introduce :（The laser shell is updated, all of which are blue shells）

GRBL Control Board:
