Model: 948-II
Parameter:
Maximum Power: 780W
Power Supply Voltage: AC 110V-127V ±10% 60Hz OR AC 200V~240V 50Hz
Plug voltage: EU 220V-240V/ US 110V-127V/ Brazil 110V-127V/ UK 220V-240V
Storage Temperature: -20~80°C/-4~176°F
Air Gun Temperature Range: 100~480
Air Mode: Brushless Fan And Soft Wind
Air Flow: less than 120L/min
Desoldering Station Power: 75W
Desoldering Station Temperature Range: 350~48
Tin Soldering Pump Power: 60W
Soldering Iron Power: 60W
Function:
1. 3 Preset channels, directly use, save time
2. Digital temperature correction, make welding temperature more accurate
3. C/F display, Allows the station to adapt user preferences in different regions
4. Sleep mode, energy saving
5. Air gun auto/manual mode allows users different frequencies to use the air gun
6. Automatic shut down
Tips:
1. Before desoldering: you need to turn the machine on, and the tin gun handle heats up to dissolve the tin of tip and then can suck to desolder
2. How to get more suck smoothly: can use the pin to clear the tin gun handle or replace the filter sponge
How to use:
Great for desoldering & soldering applications on a broad range of components. Applicable components include SOIC, CHIP, QFP, PLCC, BGA, SMD. On top of that, the station is especially suitable for desoldering in-line sockets, transformers, LCD screens, nixie tube screens, IC chips, and in-line headers. The unit's applications include heat shrinking, drying, paint removal, glue removal, defrosting, pre-heating, glue soldering, and more.
