Item Description:
Product model: ZL-14A
Dimensions: 47*27*38mm
Pre – stroke: Almost zero
Stroke/Travel: 5mm
Alarm over travel output mode: NC (Normally close)
The cutting surface size: 14mm
Cutting surface material: Hard Alloy
Cable: 5*1M 4lamp pith; Tensile Strength 20N, the minimum bending radius R7
Protecting tube: 1M (SS304), the minimum bending radius R25
Air Blow equipment: Yes
Output Mode: B: NC (Normally close)
Positioning accuracy: 0.001mm
Speed: 50-200mm/min
Use life: 3million times
Touch force: 1N
Rated Voltage: DC24V 20mA (max) recommend (10mA) resistive load
Protection class: IEC IP67
Dimensions：
