Portable AMG8833 Temperature Thermal Imager Camera Infrared Handheld Thermograph Digital High Precision Detector Sensor
Feature:
1. AMG8833 infrared thermal sensor is adopted, with stable and professional performance.
2. The module can be directly powered by USB 5V to generate infrared images.
3. The pixel is 8x8, and the farthest detection distance is 7m/23ft.
4. Small size, light and portable, easy to carry and use.
5. Made of high-quality printed circuit board, with maximum durability.
Specification:
Type: Thermal Imager
Material: printed circuit board
Color: as shown
Temperature accuracy:
Type of high performance and high gain: typical ±2.5℃ ±4.5 ℉
High performance and low gain type: typical ±3.0℃ ±5.4 ℉
Human detection distance: about 7M/22,966 feet or less (reference value)
NETD:
Typical 0.05℃ 32.900℉ 1Hz
Typical 0.16℃ 32.288℉ 10Hz
Viewing angle: 60°
Optical axis clearance: within the typical normal range of ±5.6
Current consumption:
4.5mA (normal mode)
0.2mA (sleep mode)
0.8mA (standby mode)
Number of pixels: 64 (vertical 8 x horizontal 8 matrix)
External interface: 1＞2;c (express mode)
Installation frequency: 10 frames/second or 1 frame/second
Output mode: temperature output
Temperature resolution: 0.25℃/32.45℉
Output temperature range of thermistor: -20℃-80℃(4℉-176 ℉)
Output resolution of thermistor: 0.0625℃/ 32.1125℉
Note:
Please note that the new and old models of this product will be sent randomly. Please make sure you don't mind before ordering.
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
1 x Thermal Imager
