NOTE: Limit switch and emergency stop button
Parameter:
Model:CNC 3018 Max With 500w Spindle
Engraving Area:300*180mm
Dimension(L*W*H):400*330*240mm
Construction:Aluminum
Spindle Motor:500w Spindle
Cooling :Air Cooling
Spindle Speed:11000/rpm
Power Supply:48V 10.4A
Step Motor:42 step motor 1.3A 0.25N.M
Chuck Specification:ER11 3.175MM
Supported System:Windows XP,win 7,win8,win10
Control System:GRBL, Lightburn
Limit Switch:yes
Appication:
Wood /MDF/Plastic/Leather/Stainless Steel / Aluminum / Iron
Features:CNC 3018 Max With 500w Spindle Engraving Machine has intelligent software, GRBL three-axis control board can be used on Windows System.GRBL is high performance, open-source software for controlling movement. Our machine can engrave on woods, bamboo,acrylics, PVC, PCB and so on. It is 2 in 1 cnc router,which means you can use both Carving Knife and also Laser. What’s more,it also supports Offline Controller.So you can operate it without connecting to computer.
Package Includes:Standard: CNC3018 MAX+ 4pcs clips + 10pcs cutters + 1pc ER11 collet + 2pcs wrenchsAdd Offline Controller: CNC3018 MAX+ 4pcs clips + 10pcs cutters + 1pc ER11 collet + 2pcs wrenchs + Offline ControllerAdd Laser: CNC3018 MAX + 4pcs clips + 10pcs cutters +1pc ER11 collet + 2pcs wrenchs + Goggle + Laser(Which one you choose)
