This portable vector network analyzer is a new product. It uses a 4.3-inch IPS LCD display and an aluminum alloy case. It is equipped with a 5000mAh large-capacity lithium battery as standard. Support touching screen and side button operation, support Chinese and English interface. The design of this product is based on OwOcomm's S-A-A V2, and deep optimization of the software is made on the basis of the previous product. The measurement ranges is extended to 3GHz, and the dynamic ranges is larger. The measurement is more accurate and the operation is more convenient.
Type 1
Features:
4.3-inch IPS LCD display, resolution 800*480, ultra-wide viewing angle, long-term use does not hurt your eyes.
All aluminum alloy case, effectively shielding electromagnetic interference to ensure measurement accuracy.
The radios frequency interface is SMA, which is convenient for connecting various tested parts.
Full touching screen design, with 3 side buttons at the same time, flexible and convenient operation.
Support Chinese and English interface.
Optimized UI design, convenient for users to perform measurement operations.
Support screen brightness adjustment.
The firmware can be upgraded through a virtual U disk, no programmer is needed, and the firmware can be upgraded through the included USB type-c data cable.
Standard fine quality calibration parts and RG405 phase-stable cable to ensure calibration accuracy.
Designed with USB power output interface, which can support 5V/1A power output.
Using 2A high current recharging IC, the recharging time is shorter.
Supporting host computers software, the host computers supports Chinese and English interfaces.
The screen images of the device can be obtained by taking a screenshot of the host computers.
Function: can measure S parameters, voltage standing waves ratio, Smith chart, phase, group delay, etc.
Specifications:
Material: aluminum alloy(case)
Main color: black
Battery: 1 * lithium battery, 5000mAh
Frequency: 50kHz-3GHz
RF output power: -9dBm (error within 1GHz: ±1dB)
Frequency accuracy: <0.5ppm
S21 dynamic ranges: 70dB (1.5GHz), 60dB (3GHz)
S11 dynamic ranges: 50dB (1.5GHz), 40dB (3GHz)
2-port return loss: 20dB typ (1.5GHz), 13dB min (3GHz)
Number of calibration points: 101 points
Number of scanning points: 101 points
Number of traces: 4
Number of mark points: 4 (the mark point bar can be moved up and down on the screen)
USB interface: USB Type-C communication mode: CDC (serial)
Setting save: 5 groups (after saving, it can be directly recalled when it is used again, no need to recalibrate, and the saved parameters before the last shutdown will be automatically recalled when it is turned on again)
Support calibration results interpolation, can measure without recalibration after adjusting the measurement frequency band
Scan time: about 1.9s/1 time (50kHz~3000MHz full frequency band)
Item size: 140 * 73 * 20mm / 5.5 * 2.9 * 0.8in
Item weight: 270g / 9.5ounce
Packing size: 250 * 150 * 50mm / 9.8 * 5.9 * 2.0in
Packing weight: 507g / 1.1lb
Packing List:
1 * Host
1 * SMA Open Calibration Kit
1 * SMA Short-circuit Calibration Kit
1 * SMA 50Ω Load Calibration Kit
1 * SMA-KK Double Heads Female Hole Adapter
1 * SMA-JJ Double Heads Male Pin Adapter
1 * SMA-JKW Elbow Outer Screw Inner Hole To Inner Screw Inner Adapter
2 * 200mm SMA-JJ RG405 RF Cable
1 * USB Type-C Data Cable
1 * Styluss
By the way,if you like our store,please add our store to your Favorite Stores.You can get our New arrival and Discount
information in time.
Type 2
Features:
Made of fine quality material, practical, has a long service life.
Portable and compact, easy to use and carry.
Measurement frequency range is 50KHz~3GHz.
High stability, high sensitivity, high accuracy, greatly improved performance.
Metal housing, 3.2-inch large screen is more accurate for touching, easy to operate, no need to connect power, get rid of the shackles of data cable, and can be used alone.
This product can reach 3G, can measure 2.4G antennas, can also measure duplexer, filter.
Specifications:
Material: PCB+metal
Main color: black+gold
Measurement frequency range: 50KHz-3GHz
System dynamic range (after calibration): 70dB (50k to 1.5GHz); 60dB (up to 3GHz)
S11 noise floor (after calibration): -50dB (up to 1.5GHz); -40dB (up to 3GHz)
Sweep rate: 100 points / second
Sweep points (on device): 10-201 points, adjustable
Sweep points (USB): 1-1024 points, adjustable
Power supply: USB, 4.6V–5.5V
RF port: SMA
USB interface: Micro USB
Display screen: 3.2-inch TFT
Battery: 1 * lithium battery, 1950mAh (included)
Port 2 return loss: ≥13dB (up to 3GHz), 20dB (up to 1.5GHz)
Display tracking: 4, Marking: 4, Setting save: 5
Operating ambient temperature: 0-45℃
Item size: 115 * 80 * 27mm / 4.5 * 3.1 * 1.1in
Package size: 180 * 120 * 35mm / 7.1 * 4.7 * 1.4in
Package weight: 330g / 11.6ounce
Note:
1. Software download: https://github.com/releases
2. User guide: https://github.com/raw/master/ug1101.pdf
Packing List:
1 * Vector Network Analyzer
2 * 300mm RF Cable SS405 SMA Double Male Needle
1 * USB Data Cable
1 * Calibration Kit (50Ω Load)
1 * Calibration Kit (Short)
1 * Calibration Kit (Open)
1 * SMA Female to Female Connector
By the way,if you like our store,please add our store to your Favorite Stores.You can get our New arrival and Discount
information in time.
Type 3
Features:
Made of fine quality material, practical, has a long service life.
Portable and compact, easy to operate and carry.
With housing, 2.8 inch LCD touching screen display.
Measurement frequency range is 50KHz~3GHz.
High stability, high sensitivity, high accuracy, greatly improved performance.
Specifications:
Material: PCB+acrylic
Color: black
Frequency range: 50KHz-3GHz
System dynamic range (calibrated): 70dB (up to 1.5GHz), 60dB (up to 3GHz)
S11 noise floor (calibrated): -50dB (up to 1.5GHz), -40dB (up to 3GHz)
Sweep rate: 100 points / s
Display: 2.8", 320*240
USB interface: Micro USB
Power: USB, Maximum charge current 1A
Battery: 1 * lithium battery, 1950mAh (included)
Battery connector: JST-XH 2.54mm
Maximum sweep points (on device): 201
Maximum sweep points (USB): 1024
Port 2 return loss (1.5GHz): 20dB typ
Port 2 return loss (3GHz): 13dB min
Package size: 170 * 100 * 35mm / 6.7 * 3.9 * 1.4in
Package weight: 225g / 7.9ounce
Note:
1. VNA-QT software download: https://github.com/releases
2. saver: https://github.com/zarath/tree/feature
3. User guide: https://github.com/raw/master/ug1101.pdf
Packing List:
1 * S-A-A-2 Host (with 1950mAh battery)
1 * Micro USB Data Cable
2 * 300mm SMA Male to Male SS405 RF Cable
1 * SMA Male Calibration Kit-OPEN
1 * SMA Male Calibration Kit-SHORT
1 * SMA Male Calibration Kit-LOAD
1 * SMA Female to Female Connector
1 * Set of Accessories
By the way,if you like our store,please add our store to your Favorite Stores.You can get our New arrival and Discount
information in time.
Type 4
Features:
The PC control software can export Touchstone (snp) files, which can be used for various radio design and simulation software.
The improved frequency algorithm can use the odd harmonic extension of si5351 to support the measurement frequency up to 900MHz.
The metal shield is designed to reduce the external interference and improve the measurement accuracy.
The 50k-300MHz frequency ranges of the si5351 direct output provides better than 70dB dynamic.
The extended 300M-600MHz band provides better than 50dB of dynamics, and the 600M-900M band is better than 40dB of dynamics.
Small and portable, easy to use, this project aims to provide an RF gadget but useful instrument for enthusiast.
Specifications:
Material: PCB
Color: black
Measurement frequency: 50KHz~300MHz (50KHz~900MHz, enable extended firmware)(the products will be updated with the latest firmware before shipping, the actual measurement frequency is 50KHz~900MHz)
RF output: -13dbm (maximum -9dbm)
Frequency accuracy: <0.5ppm
Measurement ranges: 70dB (50KHz-300MHz), (50dB (300M-600MHz), 40dB (600M-900MHz) enable extended firmware)
Port SWR: <1.1
Display: 2.8 inch TFT (320*240)
USB interface: USB type-C
Communication mode: CDC (serial)
Power: USB 5V 120mA, maximum recharging current 0.8A
Battery: 1 * lithium battery, 600mAh (included)
Number of calibration points: 101 (fixed)
Number of scanning points: 101 (fixed)
Display tracking: 4, Marking: 4, Setting save: 5
PCB size: 85.5 * 54 * 11mm / 3.4 * 2.1 * 0.4in (without connectors and switches)
Package size: 120 * 78 * 40mm / 4.7 * 3.1 * 1.6in
Package weight: 160g / 5.6ounce
Package list:
1 * Host
1 * USB Type-C Data Cable
2 * 30mm SMA Male to Male Cable
1 * SMA Female to Female Connector
By the way,if you like our store,please add our store to your Favorite Stores.You can get our New arrival and Discount
information in time.
