4 jaw lathe chuck 160mm SANOU Brand
Specifications:
Jaws material: Hardened Steel
Model: K12-160
Max RPM: 2500 r/min
Jaw: 4 Jaw
Power: Manual
Features:
1. Short cylindrical center mounting .
2. Model K12 chucks are provided with one- piece jaws(which include a set of internal jaws and a set of external ones ).
3 .Model K12 chucks are supplied with traditional two-piece jaws.
Internal Jaw:
Clamping Range A-A1: 3- 55mm
Jamming Range B-B1: 50- 160mm
External Jaw
Clamping Range C-C1: 55- 145mm
Packaged included :
Self-Centering chuck body x1
Inside jaws x 4
Outside jaws large x 4
Safety chuck key x 1
Mounting bolts x 3
