Highest Quality Copper Motor
No expense is spared when it comes to the design and build of this winch. Featuring the very bestcopper woundmotor (not cheap aluminium like most other brands).Giving You Full Control
This winch comes with two wireless controllers so you will be able to use your winch fromup to 100 meters away.More Power, Toughened Chassis
When you use power to create huge forces, you need a chassis that has been designed to take the strain effortlessly. This chassis ishighly toughenedto give you unbeatable strength and reliability.FEATURES
15m (49ft) of 5.5mm Galvanised Wire Rope
Stainless fairlead roller
Heavy duty winch plate included
In/out wired rocker switch
Sealed solenoid Control Box
All included accessories
Winch plate dimensions
Winch dimensions
Specifications
Rated Single Line Pull:4500lb (2045kg)
Motor:4.5hp/ Rated 3.9hp Permanent Magnet Motor
Control:Handlebar mounted rocker switch PLUS 2 x Wireless Remotes
Gear train:3 Stage Planetary
Gear reduction ratio:136 to 1
Clutch:Cam activated Free Spool
Braking Action:Dynamic
Drum size:Diameter 50mm (2.00'') Length 75mm (2.9'')
Cable:15m (49ft) of 5.5mm Galvanised Wire Rope
Fairlead:Cast 4-Way Roller Fairlead
Battery Leads:2 Gauge, 1.83m (72'') 35mmsq - 6.5mm Diameter
Finish:Black Sanded
Mounting Bolt Pattern:120mm x 76mm (4 2/3'' x 3'') Universal Standard
Motor Current:15 - 200A
No Load Line Speed:15.2m/min (49.10 ft/min)
IN THE BOX
x14500lb Winch
x1Sealed Solenoid Control Box
x14 Way Fairlead Roller
x1Heavy Duty Clevis Hook
x1Bar Mount Rocker in/out Control
x2New Style Wireless Remote Control
x1Next Generation Control Box
x115m (49ft) of 5.5mm Galvanised Wire Rope
x1Yellow Battery Cable
x1Blue Battery Cable
x1Red Battery Cable
x1Black Battery Cable
x1Set of Stainless Steel Fitting Bolts
x1Predrilled Mounting Plate
x1Box Brackets
x1Rhino Strap
x2Remote Lanyard Straps
x1User Manual
SIZE & WEIGHT
Dimensions (Boxed) L x W x H:339 x 110 x 114mm (13 1/3'' x 4 1/4'' x 4 1/4'')
Gross Weight:10KG
