Main functions:
◆ Locating & tracking buried and hidden wires .
◆ Determining Which Receptacles are on specific circuits.
◆ Pinpointing Drill Sites before drilling.
◆ White LED Flash Light .
Technical indexes:
NF-816 Transmitter specifications
Tone frequency 900Hz
The Max length distance 1000 feet
The Max depth distance 3 feet
The Max. working current Less than 70mA
Tone mode 1 Tone
Max. signal voltage 15Vp-p
Signal display Signal tone, Antenna
Voltage protection AC 60V/DC 42V
Battery type DC9.0V（NEDA 1604/6F22) x 1pc
Dimensions (LxWxD) 49 x 135 x 33mm
NF-816 Receiver specifications
Frequency 900kHz
The Max. working current Less than 70mA
Earphone jack 1
Battery type DC9.0V（NEDA 1604/6F22) x 1pc
Dimensions (LxWxD) 43 x 168 x 27mm
Attention:
1. Operate under Weak or No current.
2.Put into the right place to avoid hurting others,because of the sharp part.
3.Connected the cable to the right port.
4.Read the user manual before use it.
Package Include:
1 X transmitter ( battery is not include )
1 X receiver
