Characteristic parameters:
1. Product name: Tool setter CS-100K-30 2. Output mode: A: NO (normally open) 3. Itinerary: 5mm 4. Touch point life: 3 million times 5. Waterproof grade: IP 67 6. Repeat accuracy: 0.001 mm (condition: operating speed 50-200mm/min) 7. Contact force: 1.5N (The installation state needs to be vertical) 8. The quality of the knife surface: Super hard alloy, pure tungsten steel 9. Diameter of the knife face: Ø30mm 10. Surface treatment: Mirror grinding 4S 11. Contact point rating: DC24V 20mA (MAX) Recommended value 10mA resistive load 12. Cable specifications: Standard 3m oil resistance (length can be customized) (6 cores) 13. Indicator light: Normally closed LED lights when working
