LiteVNA64 3.95Inch
This is an portable vector network analyzer, this analyzer can meeting the ultra-wide measurement ranges of 50 kHz to 6.3 GHz. This liteVNA uses only one mixer, with multiple internal RF switches for S11 and S21 measurements, and IFFT calculations for TDR and DTF measurements. If you are interested in it, come and try it, it will not let you down.
Features:
Compare with other types, this vector network analyzer is more small, and can meeting the ultra-wide measurement ranges of 50 kHz to 6.3 GHz.
LiteVNA uses only one mixer to minimize power consumption and size, and with multiple internal RF switches for S11 and S21 measurements, and IFFT calculations for TDR and DTF measurements.
LiteVNA with faster scanning speeds and more scan points in addition to a wider measurement ranges.
LiteVNA includes a Micro memory card slot, so you can save field test data or screens to a Micro memory card at any time.
With a measurement ranges of up to 6.3GHz, the LiteVNA is capable of meeting common amateur radio and IoT applications, as well as emerging 5 GHz testing, enabling the application of the latest 5.8 GHz wifi and 5.8 GHz images transmission.
Specifications:
Material: metal
Display: 3.95inch display
Frequency ranges: 50kHz~6.3GHz
System dynamic ranges:
f < 3GHz, calibrated: >70dB
f >= 3GHz, calibrated: >50dB
S11 noise floor:
f <3GHz, calibrated: <-50dB
f >= 3GHz, calibrated: <-40dB
Frequency stability:
0℃ - 50℃: <0.5ppm
Sweep rate:
Avg=1: >550 points/s
Sweep points (on device): 10 ~ 1001 points, adjustable
Sweep points (USB): 1~1024 points
Power supplys: USB, 5V±0.5V 600mA MAX
Battery: 1 * lithium battery, 2000mAh (included)
Operation ambient temperature: -10℃~50℃
Package size: 160 * 107 * 55mm / 6.3 * 4.2 * 2.2in
Package weight: 340g / 12.0ounce
Packing list:
1 * LiteVNA Vector Network Analyzer
1 * USB Type-C Data Cable
2 * 300mm SMA Male to Male SS405 RF Cable
1 * SMA Male Calibration Kit - OPEN
1 * SMA Male Calibration Kit - SHORT
1 * SMA Male Calibration Kit - LOAD
1 * SMA Female To Female Connector
NanoVNA-F V2
Features:
4.3-inch IPS LCD display, resolution 800*480, ultra-wide viewing angle, long-term use does not hurt your eyes.
All aluminum alloy case, effectively shielding electromagnetic interference to ensure measurement accuracy.
The radios frequency interface is SMA, which is convenient for connecting various tested parts.
Full touching screen design, with 3 side buttons at the same time, flexible and convenient operation.
Support Chinese and English interface.
Optimized UI design, convenient for users to perform measurement operations.
Support screen brightness adjustment.
The firmware can be upgraded through a virtual U disk, no programmer is needed, and the firmware can be upgraded through the included USB type-c data cable.
Standard fine quality calibration parts and RG405 phase-stable cable to ensure calibration accuracy.
Designed with USB power output interface, which can support 5V/1A power output.
Using 2A high current recharging IC, the recharging time is shorter.
Supporting host computers software, the host computers supports Chinese and English interfaces.
The screen images of the device can be obtained by taking a screenshot of the host computers.
Function: can measure S parameters, voltage standing waves ratio, Smith chart, phase, group delay, etc.
Specifications:
Material: aluminum alloy(case)
Main color: black
Battery: 1 * lithium battery, 5000mAh
Frequency: 50kHz-3GHz
RF output power: -9dBm (error within 1GHz: ±1dB)
Frequency accuracy: <0.5ppm
S21 dynamic ranges: 70dB (1.5GHz), 60dB (3GHz)
S11 dynamic ranges: 50dB (1.5GHz), 40dB (3GHz)
2-port return loss: 20dB typ (1.5GHz), 13dB min (3GHz)
Number of calibration points: 101 points
Number of scanning points: 101 points
Number of traces: 4
Number of mark points: 4 (the mark point bar can be moved up and down on the screen)
USB interface: USB Type-C communication mode: CDC (serial)
Setting save: 5 groups (after saving, it can be directly recalled when it is used again, no need to recalibrate, and the saved parameters before the last shutdown will be automatically recalled when it is turned on again)
Support calibration results interpolation, can measure without recalibration after adjusting the measurement frequency band
Scan time: about 1.9s/1 time (50kHz~3000MHz full frequency band)
Item size: 140 * 73 * 20mm / 5.5 * 2.9 * 0.8in
Item weight: 270g / 9.5ounce
Packing size: 250 * 150 * 50mm / 9.8 * 5.9 * 2.0in
Packing weight: 507g / 1.1lb
Packing List:
1 * Host
1 * SMA Open Calibration Kit
1 * SMA Short-circuit Calibration Kit
1 * SMA 50Ω Load Calibration Kit
1 * SMA-KK Double Heads Female Hole Adapter
1 * SMA-JJ Double Heads Male Pin Adapter
1 * SMA-JKW Elbow Outer Screw Inner Hole To Inner Screw Inner Adapter
2 * 200mm SMA-JJ RG405 RF Cable
1 * USB Type-C Data Cable
