1 & 220vAC 2.2kw Metal Working Spindle Motor Water Cooling 800Hz Pole=4 Diameter =85mm
1 & 220v Fuling brand inverter 1000Hz
1 & 85mm Spindle bracket
1 & 75w water pump
1 & 5meter water tube
1 kits ER20 collets (4,6,8,10,12,1/8,1/4,1/2)
Size: 85x215mm (Middle body diameter:85mmxLength:215mm)
Speed Ways: Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.
Cooling:Water cooling
Power Interface: Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.
Power:2.2kw
Voltage: 220v
Current: 10A
Frequency:800Hz
Speed: 12000-24000rpm
Pole: 4
Runout Off: Less than 0.01mm
Diameter(mm): 85
Bearing Type: 2 x 7005 P4 DT & 2 x 7203 P4 DT
4pcs Ceramic Ball Bearings (fully sealed angular contact bearings)
Collet:ER20
Clip Knife diameter:13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)
Water Cooling ER20 collet chunk
Grease Lubrication
Main Application:Engrave for iron,steel,stainless steel, aluminum,hard wood etc. (This is professional metal spindle, high accuracy,big torque)
Ceramic ball bearings,full sealed angular contact ball bearings ,2×7005C P4 DT &2×7003C P4 DT,increase spindle life
Pole=4,800Hz,big torque,professional metal spindle, used for iron, steel, stainless steel etc.
Carefull assembly make the spindle more precisional.
High accuracy,used for metal engraving,cutting.Precision 0.01mm.
We are the spindle manufacturer, we offer only best quality and best price to you.
1. Our Ceramic ball bearings spindle use 4 pcs ceramic ball bearings.
2. Ceramic ball bearings are resistant to high temperatures and low heat , usually 3-5 degrees lower than steel ball bearings during using .
3. Ceramic ball bearings have low friction, low noise and long service life.
4. If you want to use the spindle for aluminum, hard wood, then ceramic ball bearings better than steel ball bearings.
Input Voltage: 220v(+/-15%)
Input Frequency: 50/60Hz
Input Phase: 1 or 3 phase
Output Voltage: 220vAC
Output Frequency: 0-1000 Hz
Output Current:10A
Output Phase: 3 phase
◆ Two speed control modes: no PG vector control (SVC), V/F control
◆ No PG vector control (SVC): starting torque 0.5Hz up to 150%
◆ 8-stage simple PLC function, multi-speed control and PID control
◆ Support multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting
◆ I/O terminals can be freely programmed to combine multiple working modes according to user needs.◆ With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.
◆ With instantaneous power-down retention function, it can avoid the impact of production due to instantaneous power failure
◆ With over torque and under torque detection
◆ Automatic voltage adjustment function to effectively solve the low frequency oscillation problem of high power motor
◆ Provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation
◆ Built-in reactor with inverter above 37kW, which improves the power factor of the input side and improves the efficiency and stability of the whole machine.
◆ 0.75~15kW built-in braking unit .
Some Qusetions about Inverter
DO NOT set up the inverter by yourself if you don't know how to, or it will make both the spindle and inverter burn easily.
Please contact us, we have manuals, videos and pictures to help you.
Max Head: 3.2 m;
Power: 75w;
Maximum flow: 3200L / H
Plug Cord Length: 1.4m
Voltage: 220V;
Frequency: 50 HZ
Outlet size: 4 and 6 mm;
Dimensions: 120 * 110 * 90mm
Features
Compared with the aluminium profile fixture,the accuracy is much higher , and it is hard to deform.
Inner wall is very smooth, outer walls is sandblasted, relatively fine uniform, but not very smooth.
Cast aluminium fixture is much heavier than aluminium profile fixture.
Product Description
Cast aluminium fixture is high quality aluminium which is casting with a special manufacturing process ,compared with ordinary aluminium ,This product has toughness, strong shock resistance, high hardness and strong antioxidant activity.
Usage
Cast aluminium fixture is mainly used for fixation of ancillary products, thereby ensuring the verticality of balancing and ancillary products, ancillary products to improve running accuracy, reduce noise, reduce the accumulated error.
Diameter: 80mm
Material: Cast Aluminium
Advantage
High Lift 、
Large Flow Rate 、
Highly Durable
、Excellent Insulation
、Can cool the machine quickly
、Good quality and long life 、
Large inventory
、Big strong power
Features
The shell is made of high quality plastic, which is anti corrosive and high durable.
Pumps have excellent insulation thanks to the motor bearing completely sealed.
Pumps combione pumping, filtered,oxygen and fountains in one.
Note
Must be used in the water.
Must cut off the electricity once the product works improperly and must maintain it after lifting it from the water.
Type: ER20 collet
Material: 65Mn Steel
Quantity: 8 pcs (4mm,6mm,8mm,10mm,12mm,1/4(6.35mm),1/8(3.175mm),1/2(12.7mm))
Precision ≤ 0.008mm
Hardened & Precision ground
Widely used in boring, milling, drilling, CNC milling machine wire tapping,engraving spindle machines,machining centers and other processing.
Spindle in the preservation and transportation, high-speed grease inside the bearing state will change, customers should be running at low speed for 30 minutes. 3000 rpm and then follow the poor increase, run 20 minutes each. Spindle and the inverter should be working together. The inverter's specifications and parameter settings need match spindles parameter.
Connect the inverter spindle, three-phase inverter power cord should be soldered in the plug 1 (U), 2 (V), 3 (W) feet, 4 feet for the ground. After the power is turned on, to observe whether the spindle rotation axis indicates the direction consistent. If inconsistency should be immediately shut down, replace the inverter and spindle connected two wires of three-phase power supply.
It should ensure that before use of water-cooled spindle, the cooling system is working properly. Every day before using the spindle must be running at low speed for 15-20 minutes. Clamping the cutters to spindle, collet nuts ,collets,cutters must be clean enough. Shank inserted into the collet must be greater than 15mm.
Water cooled spindleMUSTbe used with water pump. Otherwise the spindle will soon broken.
AC spindle motor MUST use with inverter. The power of inverter need equal or bigger than the spindle power. Before using,please set up the inverter parameters suitable for spindle. Otherwise the spindle and inverter will broken at once.
When you use the spindle,the noise is not same as always,please STOP the spindle at once. You may need to replace the spindle bearings.
If you don't know how to set up the inverter or connect the spindle to inverter,please contact us.We will help you to set up it.
Before shipping , we did the oil seal to avoid the rust during the long shipment. When you get the spindle, please clearing the oil seal before using. Thank you.
Spindle from the production - assembly - test, and finally the perfect packaging .
We will 100% guarantee security to the hands of the guests.
