Affordable Wholesale ZBAITU Laser Engraver Cutter, 80W Engraving Cutting Machine, High Power Laser Module Head with Air Assisted/Wifi Offline Pump

SKU: 1005004078092255
Safe Payment Guarantee:


【ZBAITU M37-FF80-EAIR】【Engraving&Cutting Machine】【CNC Machine】【370*370mm】


2022 Newest High Power Module with Air Assist/Wifi Offline Best Downsized Industrial High Power Laser Engraver & Cutter for business starters, hobbyists, designers, artists, home-makers, professionals.


Welcome To ZBAITU Store, Please Note:

a. Freeshipping is not means free duty from china. As we all known, import high value goods would be charged import tax in each country; AND NOT included the remote area charge too

b.Usually, we shipping out your order within 48 hours by AliExpress Standard Shipping

c. Seller's shipping methods are shipping by express company, such as Stander Shipment/DHL/FedEx/ UPS/ TNT; Please contact us!

d. It is best to buy this product with an air pump. This product does not include air pump, please buy it yourself!


Upgradedual compression technology:The ultra-fine laser focusing area is reduced to 0.08*0.08mm, and the high-density laser can easily cut 20mm thick wood and 15mm thick black acrylic; it can directly engrave mirror stainless steel metal, ceramics, glass, and the engraving speed is 40% higher than that of ordinary models. Laser sintering Temperature up to 1200°C


Air assist, metal nozzle: FF80-EAIR laser engraver module with built-in airassisted interface, Improved air valve, will improves cutting and engraving capabilities, especially reduces yellow edges when cutting wood.The head is metal to improve safety, no worry burn the plastic protective cover again.


Eye protection filter and fan design:The laser filter cover filters 98% of the ultraviolet light to the eyes. You and those around you don't need to wear goggles to get a clear view of the laser engraving. Reduce the cost of your goggles and the inconvenience of wearing them. At the same time, the protective cover increases the structural design of the blower nozzle, and the laser blows away the smoke and debris during work, making your engraving work more perfect.Cooling System, temperature sensor intelligent control + 12000 rpm 40mm cooling fan, can work continuously for 20 hours.


Sturdy and easy to install structure design:The all-aluminum alloy anodized structure design makes the machine more durable and improves the engraving accuracy. The entire structure is designed for quick assembly, which can generally be completed within 10-20 minutes.


Wide Compatibility:This machine is compatible with a variety of mature engraving software, such as LaserGRBL, LightBurn, supports Win XP/Win 7/Win 8/XP/Win 10, also supports MAC system (LightBurn), the engraving file format supports NC, BMP, JPG, PNG, DXF, etc.


Motor integrated drive module: Modular design, more stable performance, with three stepper motor drivers can provide faster moving speed, complete high-efficiency engraving, and the service life can reach 15,000 hours.


Offline work function supports long time printing:32-bit MCU motherboard. New SD card slot is added, which can control the machine by connecting to wifi and controlling the web program. you can put the file to the SD card, then start engraving or cutting, bring your more convenience.


Large size of engraving:The laser machine has a large engraving area (37X37cm), which can meet your various engraving and cutting needs. If you want bigger size, please look at ZBAITU M81 series.


Support for engraving multiple materials: Stainless steel, aluminum, plastic, ceramic, wood, bamboo, paper, leather, rubber, sponge paper, etc. (Stone, glass, reflective or transparent materials are not supported.)


Specifications:

Moldel: ZBAITU M37

Material:Aluminum alloy

Machine size:54*50*15cm

Machine weight:2.9kg

Package weight:4kg

Engraving accuracy:0.01mm

Working size:37*37cm

Carvingmaterial: Wood\bamboo\cardboard\plastic\leather\medium density fiberboard\slate\lacquered metal\mirror stainless steel, etc

Cutting material:Cardboard\non-woven\veneer\acrylic\some thin plastic sheets\sponge\MDF\Leather.etc

Focus method:Adjustable focus

Data transmission method:USB transmission, WiFi transmission

Operating software:LaserGRBL\LightBurn.etc

Support system:Win XP / Win 7 / Win 8 / XP / Win 10 /MacOSX system,engraving file format supports compatible with file format engraving with NC, BMP, JPG, PNG , DXF, etc.

Supported input formats:NC BMP JPG PNG DXF, ect


Module Model: ZBAITU FF80 EAIR

Material:Aircraft Aluminum + Brass Shell

Luminous Color:Blue

Cooling Mode:Temperature sensor intelligent control + 10000 rpm 40mm cooling fan

Dimension:4x4x12CM

Can Cut/Engrave : MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum/PVC

Module Input:40-80W

Optical power output:10W

Wavelength:450nm

Beam Shape:0.08X0.08mm

TTL&PWM Modulation:YES, Compatible with Both TTL & PWM Modulation

PWM/TTL Input:DC3.3V-12V

Drive Mode:External ACC

Safe temperature range:<60 ℃

Module weight:200g ( The lighter the weight, the smaller the move inertia, the better the performance )

Life Time:10000-20000 hours
