This handwheel can connect to our store's MACH3 USB 4 Axis 100KHz motion control card STB4100
1* CNC 4/6 Axis MPG handwheel 5V 100PPR.
( Note: If you need 12V 25PPR or 24V 100PPR MPG handwheel, please leave a message to us!!! )
Features:
- x1, x10, x100 switch
- X,Y,Z,4th axis selector switch
- LED indicator
- High quality professional chassis
- 6ft extendable high quality shielded cable cord
- Magnetic base holder can place anywhere on the machine steel surface
- Required 5V+, 150mA, power for MPG
- Phase output is A ,/A and B,/B;
- TTL output, drive capability +-20mA;
Support CNC system:
- Taiwan Pou Yuen M600 M500 M520i T300 series, Higerman, HANUC,GSK,opened NC, KND,Siemens, the NUM, Spain FAGOR (NEW, 8055I) and so on.
Wiring:
- User can wire this unit to the CNC system with easy.
