| Control software | GRBL control |
| Construction | Aluminum + plastic |
| Working area | 300*180*40mm |
| Frame size | 400*330*240mm |
| Spindle | 775 spindle motor (12-36V) 24V: 7000r/min, 36V: 9000r/min |
| Step motor | 1.3A 0.25N.m |
| Power supply | 24V 5.6A |
| Supported system | Windows XP/ Win 7/ Win 8/ Win10 Home |
| Laser (options) | 1000mw 12V 405nm2500mw/5500mw /7000mw 12V 450nm |
| Drill bits | Diameter: 3.175mm tip: 0.1mm length: 30mm |
Please Note:When the engraving machine is connected to the computer, please don't connect an external control module, otherwise it will block the communication.Important prompt: Some components and core components have been assembled, simply hand assembled according to the installation instructions, you can use the rack.
Important reminder：
1. All lasers used on this CNC machine cannot be used with any metal.
2. ER11 needs to reduce the accessories. Both the spindle and the ER11 have the correct diameter, but the ER11 is designed to have a negative tolerance to the spindle, so you can't wear it directly.
3. Offline controller supports offline work, you do not need to connect to the computer
4. We have 7 options, you can choose offline controller or laser
5. We have EU and US adapters, you can leave a message for the plug you need. Otherwise, we will send the Euro plug by default.
6. If you need more accessories, please contact us.
7. If you need the software of this engraving machine, please provide us with the email and we will send it to you.
8.Lasers above 7w can cut 3~5mm acrylic.
9.Grblcontrol (Candle) software supports c, ncc, ngc, tap, txt G-code format files.About software:cnc 3018 software:https://my.pcloud.com/publink/show?code=XZh0fSkZDn1g9WlY8dkCoFK1lGFnv5XP6PU7Grbl software:https://my.pcloud.com/publink/show?code=XZp2ldkZC2NGws1EqH5xTmTfEBTyP5VSBjBVIf you need software, please download the link above.Any questions, please feel free to contact us
WARRANTY SERVICE:We will provide a one-year warranty and we will solve all your after-sales problems!We will check all the goods before sending, we make sure you receive high quality products!
Package Include:Standard: CNC3018 PRO-Max + 4pcs clips + 10pcs cutters + 1pc ER11 collet + 2pcs wrenchsAdd Offline Controller: CNC3018 PRO-Max + 4pcs clips + 10pcs cutters + 1pc ER11 collet + 2pcs wrenchs + Offline Controller
Add Laser: CNC3018 PRO-Max + 4pcs clips + 10pcs cutters +1pc ER11 collet + 2pcs wrenchs + Goggle + Laser(Which one you choose)
CNC 3018 PRO MAXCNC 3018 PRO-M
