Product featuresThis product is a high-performance and cost-effective video microscope.1080P/60FPS(FHD);720P/120FPS(HD), no flaky and no ghostingProfessional image processing DSP, 3D noise reduction, color reproduction;Picture, Video, PlaybackSupport mouse operation + measurement function.Support HDMI+USB (UVC free drive) +WIFI (optional) output displaySupport 1X ~ 16X zoom (including 2X intelligent zoom), clear and smoothSupport full screen freeze, left and right, up and down 1/4 of the same screen.Support grid, and position, color, thin or thick are adjustable.Support AE lock, exposure compensation functionSupports automatic, manual and calibration white balanceSupports color, black and white, retro special effectsWide dynamic, contrast, saturation, resolution are adjustableSupport image horizontal mirror, vertical flipSupport function customization, App development with SDK.Support large icon operational interface, single button operation, simple and easy to use.Supports infrared remote control operation, microphone recording, buzzer promptSupport 4GB ~32GB TF card.5V ~ 12V power supply design, wide voltage input.Industrial specifications, metal shell, durable, stable SpecificationImage sensor: Panasonic 36MP 1/2.33inchPixel size：1.43um x 1.43um3.75umPicture resolution：8000*4500(16:9)、6000x4500(4:3)Video resolution：1080P/60FPS（FHD）、720P/60FPS（HD）HDMI resolution：1080P/60FPSUSB resolution：1080P/20FPS、720P/30FPS、WVGAP/60FPSWIFI output：960x540@30fps，Support Andriod / iOS（optional）Zoom：1X～16X (including 2X intelligent zoom)Exposure control: AE lock, exposure compensation (10 levels adjustable)White balance: automatic, manual (R, G, B 10 levels for option), calibration cooperationImage control: contrast, saturation, resolution 10 levels for option.Screen freeze: full screen, left and right, up and down, 1/4.Grid: 8 groups, position, color, thin and thick are adjustableMeasurement: point, line, circle, Angle (optional)Language: English, simplify Chinese, traditional ChineseMouse interface: USB, recommend to use the original mouse (optional)Infrared remote control: maximum 5 metersWIFI antenna: SMA(Optional), maximum 10 metersHDMI port ：TYPE-AUSB port：TYPE-B USB2.0Memory card: Max.32G TF cardLens：Applicable to C or CS interfacesMicroscope dimension：195mm（L）x 125mm（W）x 25mm（H）Microscope：435g（WIFI）/ 395g（No WIFI）Through the new algorithm, new design, new configuration, it will bring you a new experience of fluent, high definition ! 180X C-MOUNT LensWorking distance: 95mm
Zoom c-mount Lens
0.5X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
Size: 180mm(L) * 50mm(DIA)Working distance:145-100mm 300X C-MOUNT LensWorking distance: 95mm
Zoom c-mount Lens
1X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 300X on the display)
Size: 248mm(L) * 50mm(DIA)Working distance:110-100mm 100X C-MOUNT LensMagnification Power by 0.12 - 2X (about 8X - 100X on the display)Work distance: 100mmVisual field :2.4mm-32mmSize: 115mm(L) * 40mm(DIA)Weight: 210gWorking distance:30-280mm Feature200X Working distance:100mm -175mm500X Working distance:90mm -110mmConnector:CS C mountZoom:continouasly variable zoomObjective Magnification:0.7X - 5X(about 28 - 200X on the display)/(about 70 - 500X on the display)Eyepiece lens adapter:0.4X/1XFixed position:50mmLocking:0.7X - 5X LockingThread:42mmAuxiliary Objective Lens:0.35X, 0.5X, 2X,1X (optional)Size:132mm(L) * 55mm(DIA) / 175mm(L) * 55mm(DIA) 56 LED Adjustable Compact Microscope Ring LightProvides intense and focused shadow-free illumination56 bright white LED bulbsLighting direction changeableVariable intensity controlIntense and focused shadow-free illumination100,000 hours of lifePower input: 100-240V, 50-60HZ, auto switchingInside diameter of the ring light: 1.0" (27mm)Overall outside diameter: 1.77" (45mm)Working Distance: 27mm-120mm Package incluede:1 x Microscope Camera1 x Power Adapter (AU/EU)1 x IR remoter1 x USB Lines1 x HDMI Lines1 x WIFI antenna1 x Wipe cloth1 x User manualWIFI password: 1234567890
