Affordable Wholesale UNI-T Professional Multimeter Digital UT61B+ UT61D+ UT61E+ DC AC 1000V 60mF/220 mF Capacitance Test True RMS Auto Range Meter

SKU: 1005001637819640
Safe Payment Guarantee:







UT61E+ 1000V True RMS Digital Multimeter

UT61+ series are reliable true RMS digital multimeters with display counts 6000 (UT61B+/D+) and 22,000 (UT61E+). It can measure up to 1000V AC/DC.

Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature.

Features:
● True RMS
● Data hold/backlight
● Max/Min/Relative mode
● USB communication
● Input protection
● Diode/continuity test
● NCV (audible/visual alarm)
● LPF ACV (UT61E+)
● ACV+DCV (UT61E+)
● Transistor hFE (UT61E+)
● LoZ ACV (UT61D+)
● Peak Hold (UT61D+/UT61E+)

Notice Please: Shipping by air, battery is not included

Specifications

Range

UT61B+

UT61D+

UT61E+

Safety ratings

CAT III 1000V/CAT IV 600V

AC voltage (V)

1000V

±(1%+3)

±(1%+3)

±(0.8%+10)

DC voltage (V)

1000V

±(0.5%+3)

±(0.5%+3)

±(0.05%+5)

AC current (A)

10A

±(1.2%+5)



20A


±(1.2%+5)

±(0.8%+10)

DC current (A)

10A

±(1%+2)



20A


±(1%+2)

±(0.5%+10)

Resistance (Ω)

60MΩ

±(1%+2)

±(1%+2)


220MΩ



±(0.5%+10)

Capacitance (F)

60mF

±(3%+5)

±(3%+5)


220mF



±(3%+5)

Frequency (Hz)

10MHz

±(0.1%+4)

±(0.1%+4)


220MHz



±(0.01%+5)

Duty cycle (%)

0.1%~99.9%

±(2%+5)

±(2%+5)

±(2%+5)

Temperature (℃/℉)

-40℃~1000℃


±(1%+3)


-40℉~1832℉


±(1%+6)


Display count


6000

6000

22000

Bandwidth (Hz)


40Hz~500Hz

40Hz~1kHz

40~10kHz

LPF ACV




LoZ ACV




ACV+DCV




Transistor hFE




Peak Hold



Analog bar


31

31

46

General Characteristics

Power

1.5V battery (R03) x 4 (Not included)

Product net weight

350g

Product size

190mm x 90mm x 50mm

Standard accessories

gold plated test leads, USB cable, temperature probe (UT61D+/161D),

multi-purpose socket (only UT61E+), English manual

Standard individual packing

Gift box, cloth bag
