MHP30 Mini Hot Plate SMD Preheater Preheating Rework Station PCB Board Soldering Desoldering Heating Plate LED Strip Repair Tool
MHP30 is a super mini handheld SMD preheater with a square tower shape and detachable controller and heating plate design enable you to put it into your pocket. It has solid aluminum alloy shell with stainless steel heat dissipation slices and nano-ceramic coated brass heater plate ensure stable preheating performance. It is equipped with user-friendly functions including preset temperature, tilt heating, power wake-up, automatic sleep, firmware upgrade easy to use. Build-in OLED screen on the control to display the parameter and RGB LED indicator with various color to inform the current heating temperature easy to control. It support standard PD protocol power input support max. 60W input and 100-300 Celsius heating temperature output to meet your most preheating works ideal for reflow BGA SMD PCB board, LED strip bulbs repair , drying works.
-Model:MHP30
-Power:60W(Max.)
-Heating Plate Size: 30mm X 30mm(L*W)
-Temperature range: 100-350°C
-Temperature stability: 3%
-Ground resistance: <2Ω
-Power Supply Protocol: PD Charging
-Size: Controller: L43mm*W35mm*H31mm; Heating plate: L31mm*W31mm*H28mm
-Weight (Controller + Hot plate): 82g
Features:
1) Super mini handheld electric hot plate with a square tower shape and detachable controller and heating plate design enable you to put it into your pocket
2) Adopt miniware advanced temperature heating technology ensure fast heating speed which can reach the 300 celsius degree in 150 seconds
3) Solid aluminum alloy shell with stainless steel heat dissipation slices and nano-ceramic coated brass heater plate ensure stable preheating performance
4) Build-in OLED screen on the control to display the parameter and RGB LED indicator to inform the heating temperature easy to control
5) User-friendly functions including preset temperature, tilt heating, power wake-up, automatic sleep, firmware upgrade easy to use
6) Standard PD protocol power input support max. 60W input ensure fast and stable heating performance
7) 100-300 Celsius Heating Temperature meet your most preheating works ideal for reflow BGA SMD PCB board, LED strip bulbs repair, drying works
Package Included:
1X MPH30 Kit (NHP30 Controller+BS30 Heater)
1X TYPE C to TYPE C Cable
