Introduction:
NVEM / NVUMV2.1 is a 3-6 axis motion controller.
It is compatible with Mach3 software and standard MPG, and communicates via Ethernet and USB with computers, just using the wire to connect directly or transmit with routers.
NVEM / NVUMV2.1 motion controller adopts ARM design framework. The ARM design includes communication, collaborative analysis, underlying algorithm, and pulse generation. Reasonable design, reliable control and convenient operation.
Characteristics:
12-port photoelectric isolated input interface for ordinary digital data;
10-port photoelectric isolated output interface for ordinary digital data;
1 port 0-10V spindle speed analog output interface (can switch to PWM output)
Can support 3-6 axis stepper systems, 200KHz pulse output for each axis;
ARM motion control chip;
The main device is a 12V-32V DC power supply input, the current should be more than 0.5A;
Compatible with MPG input, Compatible with our company's MPG digital display 。.
.
Overall dimensions:
NVEM / NVUMV2.1 motion controller has sealed shell structure, there are 4 adjustment holes.
At the bottom we can fix 4 4mm diameter holes in the cabinet and install the controller in the cabinet.
The overall size of the products is 163.1mm * 80.8mm * 27.8mm;
The bottom installation size is 101.4mm * 39.5mm。
Introduction:
This MPG has a screen and 10 buttons. Coordinates and other parameters are displayed on the screen. User can change axis and speed up buttons.
Eg Zero / GOTO0 / start on button.
The encoder of NVMPG is the same as the general MPG. But the choice of axis and speed
Use USART ports instead of universal ports.
Characteristics:
High performance, low prices
2.2 inch TFT screen
10 buttons
Voltage 5VDC
8-wire control line
Coordinates / reset / FRO / SRO / SJR / 6-axis spindle are displayed on the screen
Control card wiring introduction:
