Affordable Wholesale 2.2kw ER20 air cooled spindle 4 ceramic ball bearings 24000rpm air cooling 0.01mm & 2.2kw QL VFD inverter & 80mm spindle bracket

In Stock

Affordable Wholesale 2.2kw ER20 air cooled spindle 4 ceramic ball bearings 24000rpm air cooling 0.01mm & 2.2kw QL VFD inverter & 80mm spindle bracket

SKU: 4000812746289

Safe Payment Guarantee:

1 & 220v AC 2.2kw ER20 Air Cooled Spindle Motor 80mm 4 bearings

1 & 220v 2.2kw QL VFD / Inverter

1 & 80mm Spindle Bracket / Holder

Size:80x224mm (Middle body diameter: 80mm x Length:224mm)
Speed Ways:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.
Cooling:Air cooling
Power Interface:Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.
Power:2.2kw
Voltage:220v
Current:10A
Frequency:0-400Hz
Speed: 0-24000rpm
Runout Off:Less than 0.01mm
Diameter(mm): 80
Bearing Type: 2 x 7005 P4 DT & 2 x 7002 P4 DT
4pcs fully sealed angular contact bearings
Collet: ER20
Clip Knifediameter:13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)
Air Cooling ER20 collet chunk
Grease Lubrication
Main Application:Engrave for wood,bamboo,normal PCB,PVC,PMMA,plastic,duotone board(ABS)and etc nonmetal, also can engrave on gold,silver,copper, aluminium,Pb etc soft metal surface working.(Please pay more attention, this is wood working spindle, only can used for wood working and aluminum working,please don't use it for steel. If you need steel working,please check the metal spindle,thank you!)

4 P4 angular contact bearings,2×7005C P4 DT&2×7002C P4 DT,increase spindle life
ER20 collet nut,you can use ER20 collet kits for it.
Carefull assembly make the spindle more precisional.
Runout off 0.01mm.Coaxial degree less than 0.0025mm.
Better appearance, after a long time using,still looks like new.
We are the spindle manufacturer,we offer only best quality and best price to you.

1. Our Ceramic ball bearings spindle use 4 pcs ceramic ball bearings.

2. Ceramic ball bearings are resistant to high temperatures and low heat, usually 3-5 degrees lower than steel ball bearings during using .

3. Ceramic ball bearings have low friction, low noise and long service life.

4. If you want to use the spindle for aluminum, hard wood, then ceramic ball bearings better than steel ball bearings.

Power: 2.2kw QL Inverter / VFD
Input Voltage: 220v (±20%)
Input Phase: 1 or 3 phase
Input Frequency: 50-60Hz (±5Hz)
Output Voltage: 220v
Output Phase: 3 phase
Output Current: 11A
Output Frequency: 0-1000Hz
Control Method: V/F control; Open-loop flux vector control

◆Two speed control modes: no PG vector control (SVC), V/F control

◆ No PG vector control (SVC): starting torque 0.5Hz up to 150%

◆ 8-stage simple PLC function, multi-speed control and PID control

◆ Support multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting

◆ I/O terminals can be freely programmed to combine multiple working modes according to user needs.

◆ With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.

◆ With instantaneous power-down retention function, it can avoid the impact of production due to instantaneous power failure

◆ With over torque and under torque detection

◆ Automatic voltage adjustment function to effectively solve the low frequency oscillation problem of high power motor

◆ Provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation

Application:

winding machine,mixer, extruder,slitter, winder,compressor, ventilator, pump,grinder, conveyor,elevator,centrifuger and other speed control machines.

DO NOT set up the inverter by yourself if you don't know how to, or it will make both the spindle and inverter burn easily.

Please contact us, we have manuals, videos and pictures to help you.

Diameter: 80mm

Material:Cast Aluminium

Features:

Compared with the aluminium profile fixture,the accuracy is much higher , and it is hard to deform.

Inner wall is very smooth, outer walls is sandblasted, relatively fine uniform, but not very smooth,.

Cast aluminium fixture is much heavier than aluminiumprofile fixture

Product Description:

Cast aluminium fixture is high quality aluminium which is casting with a special manufacturing process ,compared with ordinary aluminium ,This product has toughness, strong shock resistance, high hardness and strong antioxidant activity.

Usage:

Cast aluminium fixture is mainly used for fixation of ancillary products, thereby ensuring the verticality of balancing and ancillary products, ancillary products to improve running accuracy, reduce noise, reduce the accumulated error.

Spindle working environment temperature is usually -10 ~ 40 .
Before installing the first electric spindle axis head turned by hand, should feel flexible, non-blocking phenomenon.

Spindle in the preservation and transportation, high-speed grease inside the bearing state will change, customers should be running at low speed for 30 minutes. 3000 rpm and then follow the poor increase, run 20 minutes each. Spindle and the inverter should be working together. The inverter's specifications and parameter settings need match spindles parameter.(Because of high-speed grease inside the bearing state will change,when you get the spindle, maybe the noise sounds not normal.Please run it 30 minutes or even more, the noise will be normal.)
Connect the inverter spindle, three-phase inverter power cord should be soldered in the plug 1 (U), 2 (V), 3 (W) feet, 4 feet for the ground. After the power is turned on, to observe whether the spindle rotation axis indicates the direction consistent. If inconsistency should be immediately shut down, replace the inverter and spindle connected two wires of three-phase power supply.
During normal operation, air-cooled spindle often encounter the phenomenon of heat, always check whether the air-cooled spindle housing and duct clogging dust.If clogging dust, to promptly clean up. If you do not clean up, it is easily to make the spindle burned.
Every day before using the spindle must be running at low speed for 15-20 minutes. Clamping the cutters to spindle, collet nuts ,collets,cutters must be clean enough. Shank inserted into the collet must be greater than 15mm.

Spindle frequency power supply connected rated voltage, frequency should be consistent with the technical parameters of the electro-spindle, spindle speed can be adjusted to change the frequency, and voltage is proportional to the change.

Spindle being not used, the application of compressed air to blow the pipes static coolant.To prevent rust, clogging water holes. Spindle appearance should be oiled. Plus the shaft protection device, put in a dry place.

To replace the spindle bearings, certain professional and technical personnel should be replaced.Supporting special tools, bearings should be replaced fully cleaned without removing the stator coils.

Before shipping , we did the oil seal to avoid the rust during the long shipment. When you get the spindle, please clearing the oil seal before using. Thank you.

1. Cooling in different ways: water-cooled spindle motor is the use of the water cycle to cool the heat generated after the high-speed rotating spindle, spindle motor with fan-cooled approach to cooling.

2. Noise: Water-cooled spindle motor is basically no noise, but the air-cooled spindle motor is very loud.
3. Life aspects: Water-cooled spindle motor pay attention to maintenance, frequently changes the water or the use of industrial water coolers, air-cooled spindle fan mainly by the wind blowing the heat transferred to the heat sink, so as to achieve the cooling effect.
4.If you need use for metal ,hard wood,granite,stone,you can choose metal spindle.Metal spindle much better than wood spindle.

Spindle from the production - assembly - test, and finally the perfect packaging .
We will 100% guarantee security to the hands of the guests.

Affordable Wholesale 2.2kw ER20 air cooled spindle 4 ceramic ball bearings 24000rpm air cooling 0.01mm & 2.2kw QL VFD inverter & 80mm spindle bracket

1 & 220v AC 2.2kw ER20 Air Cooled Spindle Motor 80mm 4 bearings

1 & 220v 2.2kw QL VFD / Inverter

1 & 80mm Spindle Bracket / Holder

Size:80x224mm (Middle body diameter: 80mm x Length:224mm)

Speed Ways:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.

Cooling:Air cooling

Power Interface:Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.

Power:2.2kw

Voltage:220v

Current:10A

Frequency:0-400Hz

Speed: 0-24000rpm

Runout Off:Less than 0.01mm

Diameter(mm): 80

Bearing Type: 2 x 7005 P4 DT & 2 x 7002 P4 DT

4pcs fully sealed angular contact bearings

Collet: ER20

Clip Knifediameter:13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)

Air Cooling ER20 collet chunk

Grease Lubrication

4 P4 angular contact bearings,2×7005C P4 DT&2×7002C P4 DT,increase spindle life

ER20 collet nut,you can use ER20 collet kits for it.

Carefull assembly make the spindle more precisional.

Runout off 0.01mm.Coaxial degree less than 0.0025mm.

Better appearance, after a long time using,still looks like new.

We are the spindle manufacturer,we offer only best quality and best price to you.

1. Our Ceramic ball bearings spindle use 4 pcs ceramic ball bearings.

2. Ceramic ball bearings are resistant to high temperatures and low heat, usually 3-5 degrees lower than steel ball bearings during using .

3. Ceramic ball bearings have low friction, low noise and long service life.

4. If you want to use the spindle for aluminum, hard wood, then ceramic ball bearings better than steel ball bearings.

Power: 2.2kw QL Inverter / VFD

Input Voltage: 220v (±20%)

Input Phase: 1 or 3 phase

Input Frequency: 50-60Hz (±5Hz)

Output Voltage: 220v

Output Phase: 3 phase

Output Current: 11A

Output Frequency: 0-1000Hz

Control Method: V/F control; Open-loop flux vector control

◆Two speed control modes: no PG vector control (SVC), V/F control

◆ No PG vector control (SVC): starting torque 0.5Hz up to 150%

◆ 8-stage simple PLC function, multi-speed control and PID control

◆ Support multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting

◆ I/O terminals can be freely programmed to combine multiple working modes according to user needs.

◆ With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.

◆ With instantaneous power-down retention function, it can avoid the impact of production due to instantaneous power failure

◆ With over torque and under torque detection

◆ Automatic voltage adjustment function to effectively solve the low frequency oscillation problem of high power motor

◆ Provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation

Application:

winding machine,mixer, extruder,slitter, winder,compressor, ventilator, pump,grinder, conveyor,elevator,centrifuger and other speed control machines.

Diameter: 80mm

Material:Cast Aluminium

Features:

Inner wall is very smooth, outer walls is sandblasted, relatively fine uniform, but not very smooth,.

Cast aluminium fixture is much heavier than aluminiumprofile fixture

Product Description:

Cast aluminium fixture is high quality aluminium which is casting with a special manufacturing process ,compared with ordinary aluminium ,This product has toughness, strong shock resistance, high hardness and strong antioxidant activity.

Usage:

Cast aluminium fixture is mainly used for fixation of ancillary products, thereby ensuring the verticality of balancing and ancillary products, ancillary products to improve running accuracy, reduce noise, reduce the accumulated error.

Spindle working environment temperature is usually -10 ~ 40 .

Before installing the first electric spindle axis head turned by hand, should feel flexible, non-blocking phenomenon.

During normal operation, air-cooled spindle often encounter the phenomenon of heat, always check whether the air-cooled spindle housing and duct clogging dust.If clogging dust, to promptly clean up. If you do not clean up, it is easily to make the spindle burned.

Every day before using the spindle must be running at low speed for 15-20 minutes. Clamping the cutters to spindle, collet nuts ,collets,cutters must be clean enough. Shank inserted into the collet must be greater than 15mm.

Spindle frequency power supply connected rated voltage, frequency should be consistent with the technical parameters of the electro-spindle, spindle speed can be adjusted to change the frequency, and voltage is proportional to the change.

Spindle being not used, the application of compressed air to blow the pipes static coolant.To prevent rust, clogging water holes. Spindle appearance should be oiled. Plus the shaft protection device, put in a dry place.

To replace the spindle bearings, certain professional and technical personnel should be replaced.Supporting special tools, bearings should be replaced fully cleaned without removing the stator coils.

Before shipping , we did the oil seal to avoid the rust during the long shipment. When you get the spindle, please clearing the oil seal before using. Thank you.

1. Cooling in different ways: water-cooled spindle motor is the use of the water cycle to cool the heat generated after the high-speed rotating spindle, spindle motor with fan-cooled approach to cooling.

2. Noise: Water-cooled spindle motor is basically no noise, but the air-cooled spindle motor is very loud.

3. Life aspects: Water-cooled spindle motor pay attention to maintenance, frequently changes the water or the use of industrial water coolers, air-cooled spindle fan mainly by the wind blowing the heat transferred to the heat sink, so as to achieve the cooling effect.

4.If you need use for metal ,hard wood,granite,stone,you can choose metal spindle.Metal spindle much better than wood spindle.

Spindle from the production - assembly - test, and finally the perfect packaging .

We will 100% guarantee security to the hands of the guests.
